Specifications:
Processor Compatibility:
Socket Type: LGA1151
Chipset: Intel Q270
Supported Processors:
Intel Core i3-6100 / 6100T
Intel Core i3-7100 / 7100T / 7300T
Intel Core i5-6400T / 6500 / 6500T / 6600 / 6600T
Intel Core i5-7400T / 7500 / 7500T / 7600 / 7600T
Intel Core i7-6700 / 6700T / 7700 / 7700T
Memory:
Memory Type: DDR4 SODIMM
Number of Slots: 2
Supported Capacities: 4 GB, 8 GB, 16 GB per slot
Minimum RAM: 4 GB
Maximum RAM: 32 GB
Memory Speed Supported: Up to 2400MHz
Storage Interfaces:
1x M.2 slot for PCIe NVMe or SATA SSD
1x SATA port for 2.5" HDD or SSD
Expansion Slots:
1x M.2 2230 slot for WLAN
1x M.2 2280 slot for storage
I/O Ports:
Front Ports:
1x USB 3.1 Gen 1
1x USB 3.1 Gen 1 Type-C
1x USB PowerShare
Rear Ports:
4x USB 3.1 Gen 1
1x RJ-45 Ethernet
Optional:
1x Serial port
1x PS/2 keyboard + mouse combo port
1x VGA port
1x additional DisplayPort
