FSP Group 350W ATX 80 Plus Bronze Power Supply (FSP350-701UJ) - OEM

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the FSP FSP350-701UJ

Model
Brand	FSP Group
Model	FSP350-701UJ

Details
Maximum Power	350W
Output	Output Voltage: +3.3Vdc output : +3.5 Vdc minimum, + 4.8Vdc maximum +5Vdc output : +5.5 Vdc minimum, + 7Vdc maximum +12Vdc output : +13.4 Vdc minimum, + 16Vdc maximum
Input Frequency Range	47 - 63 Hz
Input Current	115V @ 6.3 Amps-rms maximum 230V @ 3.0 Amps-rms maximum
MTBF	The power supply have a minimum predicted MTBF (MIL-HDBK-217) of 100,000 hours of continuous operation at 25 degree C, maximum-output load, and nominal AC inout voltage
Efficiency	85% 230V AC
Hold-up Time	115V / 60Hz 17mSec. Minimum @ 100% Load, 230V / 50Hz 17mSec. Minimum @ 100% Load
Protection	Over current protection 3.3V:50mV p-p 5V:50mV p-p 12V1:120mV p-p 12V2:120mV p-p -12V:120mV p-p 5Vsb:50mV p-p -5V:100mV p-p

Features
Features	80 Plus Bronze Low Ripple & Noise Output over voltage protection Short circuit protection on all outputs Resettable power shut down Dual +12V output (+12V/1,+12V/2) -5V is included INTERNAL 4 cm fan 100% burn-in under high ambient temperature (50 degree C) Vacuum-impregnated transformer MTBF:100K hours at 25 degree C 100% Hi-pot tested Line input fuse protection

Dimensions & Weight
Dimensions	1.59" x 7.48" x 3.94"

Environmental
Humidity	Operating : 85% to % RH, Non-condensing Storage : 95% to % RH, Non-condensing
Temperature	Operating : 0 to +50 degree C Storage :-20 to +80 degree C

Additional Information
First Listed on Newegg	March 10, 2016

Return for refund within: 30 days

Return for replacement within: 30 days
