USB C PD 50W Notebook Power Adapter Charger w/HDMI Dongle

The Gearmo USB-C PD Notebook Power Adapter is meant to replace your existing bulky power block that your notebook computer ships with. It works with any notebook that uses a type-C port connection for its power delivery method.

The USB-C PD notebook adapter is a multi functional adapter. It can be used as a USB 3.1 Gen1 two port hub through its USB-A ports or a USB 3.1 Gen1 Type-C port, both with up to 5Gbps data transmission. The adapter also allows for an HDMI connection through its HDMI A Type receptacle. It is supplied power from a 100V~240V AC wall outlet.

Features

• 100/240VAC Universal AC input supported


• (up-stream) USB3.1 Gen1, type C, PD – 5 voltage levels supported (5V/9V/12V/15V/20V) /3A


• (down-stream) USB3.1 Gen1, type A x 2, USB 3.1 Gen1 type C x 1, 5V/3A


• Supports USB Battery Charging Specification 1.2. USB Charging Modes – SDP, CDP, DCP.


• Supports Apple, Samsung Galaxy fast charging


• HDMI A type receptacle


• Supports up to 192kHz audio frame rate and up to 24-bit audio sample size




Specifications




• 100/240VAC Universal AC input supported


• (up-stream) USB 3.1 Gen1, type C, PD – 5 output voltage levels supported


• (down-stream) USB3.1 Gen1, type A x 2, USB 3.1 Gen1 type C x 1, with individual output 5V/1.5A, and USB IF BC1.2 fast charging supported.


• HDMI type A receptacle


• AC/DC Power board is integrated inside the product, no external AC Adapter


• 80mm x 61mm x 26mm external dimension




Protections




• Over Current Protection


• Over Voltage Protection


• Over Temperature Protection


• Over Power Protection
