Gefen DVI KVM HDBaseT 2.0 Extender ???w/ RS-232 and 2-Way Audio????????? - 1 Computer(s) - 1 Remote User(s) - 492.13 ft Range - 4K - 3840 x 2160 Maximum Video Resolution - 2 x Network (RJ-45) - 7 x US

The EXT-DVIKA-HBT2 uses Gefen's implementation of the latest HDBaseT 2.0 technology to extend DVI over a single CAT-5e cable, up to 495 feet (150 meters). The new HDBaseT 2.0 Colligo platform provides additional features such as USB and 2-way audio extension and ensures an even more robust and resilient connection than the industry standard HDBaseT. Resolutions up to 1080p and 1920 x 1200 (WUXGA) are supported. HDMI resolutions up to 4K DCI-Cinema(4096 x 2160 at 30 Hz 4:4:4) and 4K Ultra HD (3840 x 2160 at 60 Hz 4:2:0) along with 7.1 channels of LPCM and HBR (High Bit Rate) lossless digital audio are also supported when using Gefen DVI to HDMI cables.

Supported HBR formats include Dolby Atmos, Dolby TrueHD, DTS:X and DTS-HD Master Audio. USB, RS-232 and 2-way L/R analog audio can be extended between the Sender and the Receiver to accommodate a complete workstation including keyboard, mouse, select USB peripherals, microphone, headphones and powered speakers. POH (Power Over HDBaseT) technology provides power from the Receiver to the Sender unit, using the same CAT-5 cable that extends the DVI, audio and control signals. Only the Receiver unit needs an external power supply. The POH standard ensures compatibility with other POH class-compliant devices.

The Gefen Syner-G software with its powerful EDID Management capabilities speeds up configuration, performs real-time performance analysis via Link Monitoring and simplifies in-field firmware updates. 1U tall, half-rack-width enclosures can be surface-mounted, installed in a standard 19-inch rack using the EXT-RACK-1U-GRY rack tray or be placed on a shelf.
