GIGABYTE G242-Z12 2U Rackmount Server Barebone Socket SP3 DDR4 3200

Be the first to review this product...
  • Socket SP3
  • Supports AMD EPYC 7003 processors with AMD 3D V-Cache Technology Compatible with AMD EPYC 7002 series processor family
  • 8 x 288Pin Memory Slots
  • 2 x 1600W redundant PSUs, 80 PLUS Platinum
This item is covered under the Manufacturer Only Return Policy.
+
+
Specs
Reviews
See all Q & A
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the GIGABYTE G242-Z12

General
Brand GIGABYTE
Model G242-Z12
Form Factor 2U Rackmount
CPU Supported
CPU Type Supports AMD EPYC 7003 processors with AMD 3D V-Cache Technology
Compatible with AMD EPYC 7002 series processor family
CPU Socket Socket SP3
Installed CPU No CPU Installed
Max Processors 2
Memory Supported
Memory Slots 8 x 288Pin
Installed Memory Size No Memory Installed
Memory Type Supported DDR4 3200
Channel Supported 8 Channel
Storage Supported
Installed HDD No Storage Installed
Graphics
GPU/VPU Aspeed AST2600
Expansion Slots
PCI Express 4 x PCIe x16 slots (Gen4 x16 bus) for GPU cards
Communications
Max. LAN Speed 1 Gigabit
Expansion Bays
Hot-Swap Bays Front side: 4 x 3.5" SATA hot-swappable HDD/SSD bays
2.5" HDD/SSD supported
SATA devices supported only

Rear side: 2 x 2.5" Gen4 U.2/SAS/SATA hybrid hot-swappable HDD/SSD bays
SAS card is required for SAS devices support
Panel Ports
Front USB 1 x USB 3.0
VGA 1
Rear USB 2 x USB 3.0
RJ45 1 x MLAN
Other Ports Internal I/O
1 x TPM header
1 x Front panel header
Power Supply
Max. Power 2 x 1600W redundant PSUs, 80 PLUS Platinum
System
System Compatibility Windows Server 2016 ( X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022

Red Hat Enterprise Linux 8.3 ( x64) or later
Red Hat Enterprise Linux 9 ( x64) or later

SUSE Linux Enterprise Server 12 SP5 ( x64) or later
SUSE Linux Enterprise Server 15 SP2 ( x64) or later

Ubuntu 18.04.5 LTS (x64) or later
Ubuntu 20.04 LTS (x64) or later
Ubuntu 22.04 LTS (x64) or later

VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later

Citrix Hypervisor 8.2.0 or later
Environment
Temperature Operating temperature: 10°C to 35°C
Non-operating temperature: -40°C to 60°C
Humidity Operating humidity: 8%-80% (non-condensing)
Non-operating humidity: 20%-95% (non-condensing)
Dimensions & Weight
Dimensions 3.44" x 17.24" x 32.28"
Additional Information
First Listed on Newegg February 04, 2025

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 3 years
  • Limited Warranty period (labor): 3 years
