GIGABYTE G593-ZD1-AAX3 Rev 3.x, HPC/AI Server - AMD EPYC 9005/9004 - 5U DP NVIDIA HGX H200 8-GPU

Be the first to review this product...
  • NVIDIA HGX™ H200 8-GPU
  • 900GB/s GPU-to-GPU bandwidth with NVIDIA® NVLink® and NVSwitch™
  • Dual AMD EPYC™ 9005/9004 Series Processors
  • 12-Channel DDR5 RDIMM, 24 x DIMMs
  • Dual ROM Architecture
  • 2 x 10Gb/s LAN ports via Intel® X710-AT2
  • 2 x M.2 slots with PCIe Gen3 x4 and x1 interface
  • 8 x 2.5" Gen5 NVMe/SATA/SAS-4 hot-swap bays
  • 4 x FHHL PCIe Gen5 x16 slots
  • 8 x LP PCIe Gen5 x16 slots
  • 6 x 3000W 80 PLUS Titanium redundant power supplies
This item is covered under the Manufacturer Only Return Policy.
Sponsored

You’re seeing this ad based on the product’s relevance to your search query. If you are a seller and want to participate in this program click here to learn more.

NEMIX RAM 32GB (1X32GB) DDR4 3200MHZ PC4-25600 2Rx8 1.2V 288-PIN ECC Unbuffered UDIMM
NEMIX RAM 32GB (1X32GB) DDR4 3200MHZ PC4-25600 2Rx8 1.2V 288-PIN ECC Unbuffered UDIMM
(15)
  •
  • $109.99 –
+
+
Specs
Reviews
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the GIGABYTE G593-ZD1-AAX3 Rev 3.x

General
Brand GIGABYTE
Model G593-ZD1-AAX3 Rev 3.x
Form Factor 5U Rackmount
Workload AI/ML/HPC
CPU Supported
CPU Type AMD EPYC 9005 & 9004 Series
CPU Socket Dual Socket SP5
CPU Features Dual processor, cTDP up to 400W
- At ambient 25C, cTDP up to 500W
Memory Supported
Memory Slots 24 x DIMM slots
DDR5 memory supported
12-Channel memory architecture
Max Memory Supported AMD EPYC 9005: RDIMM: Up to 6000 MT/s
AMD EPYC 9004: RDIMM: Up to 4800 MT/s
Channel Supported 12 Channel
Registered Yes
Storage Supported
Serial ATA 8 x 2.5" Gen5 NVMe/SATA/SAS-4 - (NVMe from PEX89104)
SATA RAID Require RAID add-in cards
SAS Require SAS add-in cards
M.2 1 x M.2 (2280/22110), PCIe Gen3 x4, from CPU_1
1 x M.2 (2280/22110), PCIe Gen3 x1, from CPU_0
Graphics
GPU/VPU NVIDIA HGX H200 with 8 x SXM GPUs (pre-installed)
Expansion Slots
PCI Express Extension Board CPBG044 x 2: 8 x LP x16 (Gen5 x16), from PEX89104
Riser Card CPBGD20 x 2: 4 x FHHL x16 (Gen5 x16), from PEX89048
AGP VGA port
Communications
First LAN Front:
2 x 10Gb/s LAN (1 x Intel X710-AT2)
- Support NCSI function
1 x 10/100/1000 Mbps Management LAN
Second LAN Rear (MLAN board - CDB66): 1 x 10/100/1000 Mbps Management LAN
Max. LAN Speed 10 Gigabit
Expansion Bays
2.5" Bays Front hot-swap:
8 x 2.5" Gen5 NVMe/SATA/SAS-4 - (NVMe from PEX89104)
Panel Ports
VGA Integrated in Aspeed® AST2600 - 1 x VGA port
Other Ports Front I/O
2 x USB 3.2 Gen1 ports (Type-A)
1 x VGA port
2 x RJ45 ports
1 x MLAN port (default)
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x Storage activity LED
1 x System status LED

Rear I/O
MLAN board - CDB66:
1 x MLAN port
Power Supply
Max. Power 5+1 3000W 80 PLUS Titanium redundant power supplies

AC Input:
- 115-127V~/ 14.2A, 50-60Hz
- 200-220V~/ 15.8A, 50-60Hz
- 220-240V~/ 14.9A, 50-60Hz

DC Input: (Only for China)
- 240Vdc/ 14A

DC Output:
- Max 1450W/ 115-127V~
+54V/ 26.6A
+12Vsb/ 3A
- Max 2900W/ 200-220V~
+54V/ 53.4A
+12Vsb/ 3A
- Max 3002.4W/ 220-240V~ or 240Vdc Input
+54V/ 55.6A
+12Vsb/ 3A
Cooling
Fans Motherboard:
2 x 40x40x56mm (32,000rpm)
4 x 60x60x56mm (24,000rpm)

PCIe slots:
4 x 40x40x28mm (25,000rpm)
2 x 40x40x56mm (32,000rpm)

GPU tray:
6 x 60x60x76mm (21,700rpm)
11 x 80x80x80mm (17,000rpm)
Environment
Hardware Monitor System Management
Aspeed AST2600 Baseboard Management Controller
GIGABYTE Management Console web interface

Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings
Temperature Operating temperature: 10C to 35C
Non-operating temperature: -40C to 60C
Humidity Operating humidity: 8%-80% (non-condensing)
Non-operating humidity: 20%-95% (non-condensing)
Dimensions & Weight
Dimensions 1200 x 890 x 700 mm
Packaging
Package Contents 1 x G593-ZD1-AAX3
2 x CPU heatsinks
1 x L-shape Rail kit
Additional Information
First Listed on Newegg November 04, 2024
