Brand | GIGABYTE |
---|---|
Model | GA-MA78GM-S2HP |
CPU Socket Type | AM2+/AM2 |
---|---|
CPU Type | Phenom FX / Phenom / Athlon 64 FX / Athlon 64 X2 |
FSB | 2600 MHz |
Chipset | AMD 780G |
---|---|
South Bridge | AMD SB700 |
Number of Memory Slots | 4x240pin |
---|---|
Memory Standard | DDR2 1066(depends on CPU)/800 |
Maximum Memory Supported | 8GB |
Channel Supported | Dual Channel |
PCI Express 2.0 x16 | 1 x PCI Express 2.0 x16 |
---|---|
PCI Express x1 | 1 x PCI Express x1 |
PCI Slots | 2 x PCI Slots |
PATA | 1 x ATA100 2 Dev. Max |
---|---|
SATA 3Gb/s | 5 x SATA 3Gb/s |
SATA RAID | 0/1/10 |
Onboard Video Chipset | ATI Radeon HD 3200 |
---|
Audio Chipset | Realtek ALC889A |
---|---|
Audio Channels | 8 Channels |
LAN Chipset | Realtek 8111C |
---|---|
Max LAN Speed | 10/100/1000Mbps |
PS/2 | 2 |
---|---|
Video Ports | D-Sub + DVI |
HDMI | 1 x HDMI |
USB 1.1/2.0 | 4 x USB 2.0 |
IEEE 1394 | 1 x IEEE 1394a |
eSATA | 1 x eSATA 3Gb/s |
S/PDIF Out | 1 x Optical |
Audio Ports | 6 Ports |
Onboard USB | 4 x USB 2.0/1.1 headers |
---|---|
Onboard 1394 | 1 x 1394a |
Form Factor | Micro ATX |
---|---|
Dimensions (W x L) | 9.6" x 9.6" |
Power Pin | 24 Pin |
Windows Vista | Certified for Windows Vista |
---|
Date First Available | November 14, 2008 |
---|
Pros: Great board for my HTPC, had what I wanted mainly the HDMI. Setup was a breeze, read the manual for HDMI usage.
Cons: Had some trouble with VMC 64 bit and HDMI audio for DVD playback. After reading the manual and updating the bios for HDMI the sound worked beautifully for windows but nothing for VMC DVD playback. I spent probably 10 hours trying to figure it out. It all came down to opening the HDMI device manager and UNCHECKING the box saying "Allow other programs to control this device." (Not the exact words but it's in the advanced settings.)
Overall Review: I don't think the problem I had, had anything to do with the motherboard. Maybe just the way the drivers and worked. Anyways I hope this helps anyone trying to set up a HTPC with this mother board using HDMI.
