Brand | GIGABYTE |
---|---|
Model | N4120I H |
Combo Type | Motherboard / CPU Combo |
CPU | Intel Celeron N4120 2.60 GHz |
---|---|
Color | Black |
CPU Type | Celeron |
---|
Number of Memory Slots | 2x288pin (DDR4) |
---|---|
Memory Standard | DDR4 2400 |
Maximum Memory Supported | 16GB |
Channel Supported | Dual Channel |
PCI Express x1 | 1 x PCI Express x1 slot, running at x1 (The PCIEX1 slot conforms to PCI Express 2.0 standard.) |
---|---|
Other Slots | 1 x M.2 Socket 1 connector for the wireless communication module 1 x M.2 connector (Socket 3, M key, type 2280/2260/2242 SATA and PCIe 2.0 x2 SSD support) |
SATA | 2 x SATA 6.0Gb/s |
---|
LAN Speed | 10/100/1000Mbps |
---|---|
Max LAN Speed | 1Gbps |
PS/2 | 1 x PS/2 keyboard port 1 x PS/2 mouse port |
---|---|
Video Ports | 1 x D-Sub port |
HDMI | 1 x HDMI |
RJ45 | 1 x RJ45 |
USB 1.1/2.0 | 2 x USB 2.0/1.1 ports |
USB 3.0 | 2 x USB 3.2 Gen 1 ports |
Audio Ports | 3 Ports |
Onboard USB | 2 x USB 3.2 Gen 1 ports (2 ports available through the internal USB header) 2 x USB 2.0/1.1 ports (2 ports available through the internal USB header) |
---|---|
Other Connectors | 1 x 24-pin ATX main power connector 1 x 4-pin ATX 12V power connector 2 x SATA 6Gb/s connectors 1 x SoC fan header 1 x system fan header 1 x M.2 Socket 3 connector 1 x front panel header 1 x front panel audio header 1 x parallel port header 1 x serial port header 1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only) 1 x Clear CMOS jumper |
Features | Support for Xpress Install Support for @BIOS Support for APP Center * Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. |
---|
Form Factor | Mini ITX |
---|---|
Dimensions (W x L) | 6.7" x 6.7" |
Date First Available | June 09, 2025 |
---|
