GIGABYTE R282-Z92 Rack Server - AMD EPYC™ 7002/7001 - 2U DP 24+2-Bay Gen3 NVMe/SATA/SAS

Be the first to review this product...
  • Dual AMD EPYC™ 7002/7001 Series Processors
  • 8-Channel DDR4 RDIMM/LRDIMM, 32 x DIMMs
  • 2 x 1Gb/s LAN ports via Intel® I350-AM2
  • 24 x 2.5" Gen3 NVMe hot-swappable bays
  • 2 x 2.5" SATA/SAS hot-swappable bays on the rear side
  • 1 x M.2 slot with PCIe Gen3 x4 interface
  • 2 x FHHL PCIe Gen4 x8 slots
  • 1+1 1600W 80 PLUS Platinum redundant power supplies
View User Manual Details
This item is covered under the Manufacturer Only Return Policy.
+
+
Specs
Reviews
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the GIGABYTE R282-Z92 v.100

General
Brand GIGABYTE
Model R282-Z92 v.100
Form Factor 2U Rackmount
Workload General Purpose Server
CPU Supported
CPU Type AMD EPYC 7002/7001 Series
CPU Socket Socket SP3
Installed CPU No CPU Installed
Max Processors 2
CPU Features Dual processor, 7nm technology
Up to 64 cores, 128 threads per processor
cTDP up to 280W
Memory Supported
Memory Slots 32 x 288Pin
Installed Memory Size No Memory Installed
Max Memory Supported 4TB
Memory Type Supported Memory speed: Up to 3200*/2933 MT/s

*Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.
Channel Supported 8 Channel
Registered Yes
Storage Supported
Installed HDD No Storage Installed
M.2 1 x M.2 slot:
- M-key
- PCIe Gen3 x4, from CPU_0
- Supports 2242/2260/2280/22110 cards
- CPU TDP is limited to 225W if using M.2 device
Graphics
GPU/VPU Aspeed AST2500
Expansion Slots
PCI Express 2 x FHHL PCIe Gen4 x8 slots
Communications
First LAN Intel I350-AM2
Max. LAN Speed 1 Gigabit
Expansion Bays
Hot-Swap Bays Front side:
24 x 2.5" Gen3 NVMe hot-swappable bays
- (12 x from CPU_0, 12 x from CPU_1)

Rear side:
2 x 2.5" SATA/SAS hot-swappable bays, from CPU_1
Panel Ports
Buttons 1 x NMI button
1 x Reset button
LEDs 1 x Power button with LED
1 x ID button with LED
2 x LAN activity LEDs
1 x Storage activity LED
1 x System status LED
Front USB 2 x USB 3.0
VGA 1
Rear USB 2 x USB 3.0
RJ45 2
Other Ports 1 x MLAN
Power Supply
Max. Power 1+1 1600W 80 PLUS Platinum redundant power supplies
System
System Compatibility Citrix Hypervisor 8.1.0 or later

Red Hat Enterprise Linux 7.6 or later
Red Hat Enterprise Linux 8.0 or later
Red Hat Enterprise Linux 9.0 or later

SUSE Linux Enterprise Server 12 SP4 or later
SUSE Linux Enterprise Server 15 SP1 or later

Ubuntu 16.04.6 LTS or later
Ubuntu 18.04.3 LTS or later
Ubuntu 20.04 LTS or later

VMware ESXi 6.5 EP15 or later
VMware ESXi 6.7 Update3 or later
VMware ESXi 7.0 or later
VMware ESXi 8.0 or later

Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Cooling
Fans 4 x 80x80x38mm (16,300rpm)
Environment
Temperature Operating temperature: 10°C to 35°C
Non-operating temperature: -40°C to 60°C
Humidity Operating humidity: 8%-80% (non-condensing)
Non-operating humidity: 20%-95% (non-condensing)
Dimensions & Weight
Dimensions 3.43" x 17.24" x 28.74"
Packaging
Package Contents 1 x R282-Z92
2 x CPU heatsinks
1 x 2-Section Rail kit
Additional Information
