Brand | GIGABYTE |
---|---|
Model | R282-Z92 v.100 |
Form Factor | 2U Rackmount |
Workload | General Purpose Server |
CPU Type | AMD EPYC 7002/7001 Series |
---|---|
CPU Socket | Socket SP3 |
Installed CPU | No CPU Installed |
Max Processors | 2 |
CPU Features | Dual processor, 7nm technology Up to 64 cores, 128 threads per processor cTDP up to 280W |
Memory Slots | 32 x 288Pin |
---|---|
Installed Memory Size | No Memory Installed |
Max Memory Supported | 4TB |
Memory Type Supported | Memory speed: Up to 3200*/2933 MT/s *Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC. |
Channel Supported | 8 Channel |
Registered | Yes |
Installed HDD | No Storage Installed |
---|---|
M.2 | 1 x M.2 slot: - M-key - PCIe Gen3 x4, from CPU_0 - Supports 2242/2260/2280/22110 cards - CPU TDP is limited to 225W if using M.2 device |
GPU/VPU | Aspeed AST2500 |
---|
PCI Express | 2 x FHHL PCIe Gen4 x8 slots |
---|
First LAN | Intel I350-AM2 |
---|---|
Max. LAN Speed | 1 Gigabit |
Hot-Swap Bays | Front side: 24 x 2.5" Gen3 NVMe hot-swappable bays - (12 x from CPU_0, 12 x from CPU_1) Rear side: 2 x 2.5" SATA/SAS hot-swappable bays, from CPU_1 |
---|
Buttons | 1 x NMI button 1 x Reset button |
---|---|
LEDs | 1 x Power button with LED 1 x ID button with LED 2 x LAN activity LEDs 1 x Storage activity LED 1 x System status LED |
Front USB | 2 x USB 3.0 |
VGA | 1 |
Rear USB | 2 x USB 3.0 |
RJ45 | 2 |
Other Ports | 1 x MLAN |
Max. Power | 1+1 1600W 80 PLUS Platinum redundant power supplies |
---|
System Compatibility | Citrix Hypervisor 8.1.0 or later Red Hat Enterprise Linux 7.6 or later Red Hat Enterprise Linux 8.0 or later Red Hat Enterprise Linux 9.0 or later SUSE Linux Enterprise Server 12 SP4 or later SUSE Linux Enterprise Server 15 SP1 or later Ubuntu 16.04.6 LTS or later Ubuntu 18.04.3 LTS or later Ubuntu 20.04 LTS or later VMware ESXi 6.5 EP15 or later VMware ESXi 6.7 Update3 or later VMware ESXi 7.0 or later VMware ESXi 8.0 or later Windows Server 2016 (X2APIC/256T not supported) Windows Server 2019 |
---|
Fans | 4 x 80x80x38mm (16,300rpm) |
---|
Temperature | Operating temperature: 10°C to 35°C Non-operating temperature: -40°C to 60°C |
---|---|
Humidity | Operating humidity: 8%-80% (non-condensing) Non-operating humidity: 20%-95% (non-condensing) |
Dimensions | 3.43" x 17.24" x 28.74" |
---|
Package Contents | 1 x R282-Z92 2 x CPU heatsinks 1 x 2-Section Rail kit |
---|
First Listed on Newegg | February 10, 2025 |
---|
