Question 1

how many RAM slots?

Accepted Answer

4 x DDR4 DIMM sockets supporting up to 64 GB of system memory

Dual channel memory architecture

Support for DDR4 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) / 3000(O.C.) / 2800(O.C.) / 2666 / 2400 / 2133 MHz memory modules

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP) memory modules

Question 2

Will this SSD work with this board? (SAMSUNG 850 EVO 2.5" 500GB MZ-75E500B/AM)
Thanks

Accepted Answer

Hello, I do not see why there is incompatibility, both of which have SATA III connection. The SAMSUNG 850 EVO communicates with the MB using SATA (6.0Gbit / s = SATA III) data connection and the motherboard has 6 6.0Gbit / s (SATA III) connectors. I even bought an 850 EVO of 240GB to put in my GB Z370 GAMING 5, but I am still not with both on hand to test them, but I do not believe in their incompatibility.

Question 3

does this motherboard work with a core i7-6700?

Accepted Answer

No, this is z370 motherboard, only works with 8th generation intel cpu. For i7 6700 you have to get intel B,H, Z170 or Z270 motherboards.

Question 4

Would a gtx 1070 work with this board?

Accepted Answer

Yes, I currently use a Nvidia GTX1070 with this mobo. I am using a EK waterblock though, but the card sits the same again the I/O panel area and doesn’t have interference with the audio plastic panel along the rear that some people say video cards hit against. It’s close, but it fits fine and no contact with any parts.

Question 5

will a kaby lake 7700 91 watt work with this board?

Accepted Answer

Unfortunately not. As the product description states, this is only for the 8th generation Intel processors and the 7700 is a 7th generation. These are not backwards compatible even though they utilize the same socket type. You will require the 100 or 200 series of their motherboards to be compatible. Use this website to check all usable motherboards for gigabyte.
http://www.gigabyte.us/Support/CPU Support
Most companies provide this type of site so you could Google if you wanted to check Asus or a asrock

Question 6

Can I raid 0 with all 3 m.2 slots? Two of the three slots are pcie/sata compatible while the 3rd is only pcie. I have three intel 530 series m.2 sata ssd lying around and I want to raid 0 them.

Accepted Answer

No, only the top two M.2 slots will work for RAID. I have tried the lower slot and it will not be recognized for RAID array setup.

Question 7

What is the different between this version and the Gaming 7? It seems like this is a better deal since it also has Wifi AC?

Accepted Answer

Gaming 5 has wifi, gaming 7 has a water block built in for custom water cooling. Make sure to look at all of the 1-star reviews on the gaming series bords before you buy one. There are a few issues left to resolve. Stil a good board.

Question 8

How good is the on board wifi? do i need to buy a separate wifi card/adapter?

Accepted Answer

The onboard WiFi works extremely well.  You’ll need to install the WiFi driver from the motherboard disk once you’re up and running, then update the driver through Windows Device Manager.

Question 9

What type of heatsink would be best to use for the CPU?

Accepted Answer

Any heatsink that fits a socket LGA 1151 will work. Other than that it's up to personal preference.

Question 10

Will CORSAIR Vengeance LPX 16GB (2 x 8GB) 288-Pin DDR4 SDRAM DDR4 2133 (PC4 17000) work with this board?

Accepted Answer

I use Corsair Vengeance LPX 16GB (2x8GB) DDR4 DRAM 3000MHz C15 Desktop Memory Kit - Black (CMK16GX4M2B3000C15) Works absolutely perfectly.
