    AsRock Rack 1U4LW-X470 1U Rackmount Server Barebone AMD AM4 Ryzen & Ryzen 7nm PGA1331 X470 4 x 3.5" HDD 400W PSU

    (7) Write a Review
    • 1U Rackmount with 400W PSU
    • Support AMD AM4 Socket Ryzen Series CPUs and Ryzen 7nm CPUs
    • Support 4 x DDR4 ECC and non-ECC UDIMM, max. 128 GB
    • Support externall 4 x 3.5" HDD or 2.5" HDD, internal 2 x 2.5" HDD, external: 1 x Slim ODD or 1 x 2.5" HDD (optional)
    • Support 1 x PCIe 3.0 x16 single-width Full Height card (by Riser card)
    • Support 2 x RJ45 GLAN by Intel i210 + 1 x Dedicated IPMI LAN
    • General-purpose Server
    +
    +
    Specs
    Reviews (7)
    avatar

    Any questions? Our AI beta will help you find out quickly.

    Try me now

    Learn more about the ASRock Rack 1U4LW-X470

    Best Seller Ranking #9 in Server Barebones
    General
    Brand ASRock Rack
    Model 1U4LW-X470
    Form Factor 1U Rackmount
    Workload General Purpose Server
    CPU Supported
    CPU Type AMD AM4 Socket Ryzen PRO/ Ryzen 2nd and 3rd generation series processors
    CPU Socket AM4
    Chipset
    North Bridge AMD X470
    Memory Supported
    Installed Memory Size No Memory Installed
    Max Memory Supported 128GB
    Memory Type Supported Supports DDR4 ECC / UDIMM, up to 2667 MHz
    Channel Supported Dual Channel
    Storage Supported
    Serial ATA 6 x SATA3 6.0 Gb/s (1x SATA DOM port), support RAID 0, 1, 10
    Graphics
    GPU/VPU Aspeed AST2500
    Video Memory 16MB DDR4
    Expansion Slots
    PCI Express PCIe 3.0 x16
    - PCIE6: Gen3 x16 link (splittable in x4/4/4/4); auto switch to x8 link when PCIE4 is occupied.
    - SLOT4: Gen3 x8 link

    PCIe 3.0 x8
    - SLOT5: Gen3 x4 link
    Communications
    First LAN Intel I210
    Max. LAN Speed 1 Gigabit
    Panel Ports
    Rear USB 2 x USB 3.2 Gen 1
    Power Supply
    Max. Power Type: Single PSU
    Output Watts : 400W
    Features
    Features 1U Rackmount with 400W PSU
    Supports AMD AM4 Socket Ryzen Series CPUs and Ryzen 7nm CPUs
    Supports 4x DDR4 ECC and non-ECC UDIMM, max. 128 GB
    Supports external 4 x 3.5'' HDD or 2.5'' HDD, internal 2x 2.5'' HDD, external: Slim ODD x1 or 2.5" HDD x1 (optional)
    Supports 1x PCIe 3.0 x16
    Supports Intel i210 x2
    ASPEED 2500 for BMC controller, Realtek RTL8211E for dedicated IPMI GLAN
    Dimensions & Weight
    Dimensions 1.75" x 21.00" x 19.00"
    Additional Information
    First Listed on Newegg September 19, 2019

    Warranty & Returns

    Warranty, Returns, And Additional Information

    Warranty

    • Limited Warranty period (parts): 3 years
    • Limited Warranty period (labor): 3 years
