Video: Video Input:
Interfaces: 1 x HDMI Type A Female (Black)
Impedance: 100 O
Max. Distance: 3 m
Video:
Max. Data Rate: 10.2Gbps (3.4Gbps per lane)
Max. Pixel Clock: 340 MHz
Compliance: HDMI (3D, Deep Color, 4K), HDCP2.2 Compatible, Consumer Electronics Control (CEC)
Max. Resolutions / Distance: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a/ATEN 2L-2910 Cat6); 1080p@100m (Cat 5e/6/6a); *4K supported: 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Audio: Audio Input: 1 x HDMI Type A Female (Black)
Other Connector: Unit To Unit: 1 x RJ-45 Female
Firmware Upgrade: 1 x Mini Stereo Jack Female (Black)
Power: 1 x DC Jack (Black) with locking
Power Consumption: DC5V:1.708W:8BTU/h
DC5V:1.649W:50BTU/ h
Note:
? The measurement in Watts indicates the typical power consumption of the device with no external loading.
? The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
Specification: Operating Temperature 0°C to 50°C
Storage Temperature -20°C to 70°C
Humidity 0–80% RH, Non-condensing
Local Unit
Upstream Port 1 x USB Type B Female
Downstream Port 1 x RJ45 Female
1 x Micro USB Female (Firmware Upgrade)
Power 1 x DC Jack
Remote Unit
Upstream Port 1 x RJ45 Female
Downstream Port 4 x USB Type A Female
1 x Micro USB Female (Firmware Upgrade)
Power 1 x DC Jack
USB Specification USB 2.0 High-Speed
Cable Type Ethernet Cable
Network Interface: Side A: RJ45 (FEMALE)
Side B: RJ45 (FEMALE)
VGA: Side A: 2 x HD15 (FEMALE)
Side B: HD15 (FEMALE)
Analog Aduio: Side A: 2 x 3.5MM (FEMALE)
Side B: 3.5MM (FEMALE)
Specification: COMMUNICATIONS
Max 1024 x 768 Range (ft.): 1000
Max 480P Range (ft.): 1000
Max 1440 x 900 Range (ft.): 500
Max 1080i Range (ft.): 500
Max 1080P Range (ft.): 500
Max 1920 x 1440 Range (ft.): 500
Max 480i Range (ft.): 1000
Max 640 x 480 Range (ft.): 1000
Max 800 x 600 Range (ft.): 1000
Max 1600 x 1200 Range (ft.): 500
Max 1920 x 1200 Range (ft.): 500
Max 720P Range (ft.): 500
Distance: up to 200 ft. at 1024 x 768 (60Hz)
up to 150 ft. at 1920 x 1080 (60Hz)
Color: Black
LED Indicator: The Green RJ45 LED on the local unit illuminates to indicate it is connected to and receiving power from the source. The Orange RJ45 LED on the local unit does not illuminate. The Green RJ45 LED on the remote unit illuminates to indicate it is receiving power from the external power supply. The Orange RJ45 LED on the remote unit illuminates to indicate it is connected to the local unit and receiving a signal from the source.
Power Consumption: VE801T: DC5V, 1.85W
VE801R: DC5V, 4.23W
Specification: Video Input
Interface: 1 x HDMI Type A Female (Black)
Impedance: 100?
Max distance: 1.8 m
Video Output
Interface: 1 x HDMI Type A Female (Black)
Impedance: 100?
Video
Max. data rate: 10.2Gbps (3.4Gbps per lane)
Max. pixel clock: 340 MHz
Compliance: HDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
Max resolutions / Distance: Up to 4K@35m (Cat 5e/6) / 40m (Cat 6a);
1080p@60m (Cat 5e/6) / 70m (Cat 6a)
Audio
Input: 1 x HDMI Type A Female (Black)
Output: 1 x HDMI Type A Female (Black)
Power
Connector: 1 x DC Jack (Black) with locking
Environment
Operating Temp.: 0-50°C
Storage Temp.: -20°C - 60°C
Humidity: 40% - 85% RH, Non-condensi...
