Resolution Support: Maximum Digital Resolutions: 3840 x 2160 (4K) @ 60 Hz
Supported Resolutions:
3840 x 2160 (4K) 60 Hz
2560 x 1600 60 Hz
1920 x 1200 60 Hz
1920 x 1080 (1080p) 60 Hz
1280 x 720 (720p) 60 Hz
* Lower resolutions and refresh rates, not stated but below the maximum, may also be supported
Audio: 7.1 Surround Sound
HDMI: Connector A: 1 x HDMI (19-pin) Female
Connector B: 1 x HDMI (19-pin) Female
Distance: Maximum Distances - (1080i only)
CAT5E (stranded) - 40m (130 ft.)
CAT5E (solid) - 50m (165 ft.)
CAT6 (stranded or solid) - 50m (165 ft.)
Max Distance: 50m / 165 ft.
Resolution Support: Maximum Digital Resolutions: 1080p / 1920x1080
Supported Resolutions:
1080i
- Cat6 (stranded or solid) - up to 50m
- Cat5e (solid) - up to 50m
- Cat5e (stranded) - up to 40m
1080p
- Cat6 (solid or stranded) - up to 40m
- Cat5 (solid) - up to 20m
- Cat5 (stranded) - up to 16m
See product manual for further details
HDMI: Local Unit Connectors:
1 x HDMI (19-pin) Female
Remote Unit Connectors:
1 x HDMI (19-pin) Female
Network Interface: Local Unit Connectors:
2 x RJ-45 Female
Remote Unit Connectors:
2 x RJ-45 Female
Power Supply: Input: 100-240V, 50/60Hz, 1.5A
Output: 12.6V, 3A
Specification: Cable Type: VGA
Display Style: Splitter
Color: Black
Connector A: HD15 (FEMALE)
Connector B: RJ45 (FEMALE) x 4
Feature: Splits a single VGA signal into 5 (1 local, 4 remote)
Increase the number of displays to up to 25 (1 local, 24 remote) by daisychaining up to six B132-004-2 units together
A B132-100-1 or B132-100-WP-1 remote receiver unit is required for each connected monitor
Extends a 1920 x 1440 (60Hz) signal up to 500 ft., or a 1024 x 768 (60Hz) signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable, such as Tripp Lite's N022-01K-GY (Cat5) and N222-01K-GY (Cat6)
EDID copy feature ensures optimal display compatibility
The range and number of monitors can be further expanded by adding B132-110 repeater units
Connect up to 4 remote unit...
Specification: Hardware
Audio: Yes
Cabling: Cat 5e UTP or better
Daisy-Chain: No
Output Signal: HDMI
Ports: 1
Rack-Mountable: Yes
Performance
Audio Specifications: 7.1 Surround Sound
Max Distance: 70 m / 230 ft
Maximum Cable Length: 0.2 ft [0.1 m]
Maximum Digital Resolutions: 4096 x 2160 (4K) @ 30 Hz
Wide Screen Supported: Yes
Connector(s)
Connector A:
- 1 x HDMI (19 pin) Female Input
- 1 x
Feature: Extend HDMI video over CAT5 or CAT6 cabling up to 230 feet away, with a small USB-powered transmitter for discreet installation
Works with HDMI video sources such as Blu-ray players & computers and HDMI televisions monitors and projectors
HDBaseT Extender / HDMI over single CAT 5 or CAT 6 Ethernet Extender /
Resolution Support: Up to 4K@70m (Cat 5e/6) / 100m (Cat 6a);
1080p@100m
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60 Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30 Hz (4:4:4)
Video: Max. Data Rate: 10.2 Gbps (3.4 Gbps Per Lane)
Max. Pixel Clock: Up to 340 MHz
Compliance:
HDMI (3D, Deep Color, 4K)
HDCP Compatible
Consumer Electronics Control (CEC)
Resolution Support: Up to 4K@35m (Cat 5e/6) / 40m (Cat 6a); 1080p@60m (Cat 5e/6) / 70m (Cat 6a)
*4K supported:
4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0); 4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4)
Power Supply: VE802R
Connectors: 1 x DC Jack (Black) with locking
Consumption: DC 5V, 4W
VE802T
Connectors: 1 x DC Jack (Black) with locking
Consumption: DC 5V, 3.6W
Feature: The VE802 HDMI HDBaseT-Lite Extender extends an HDBaseT signal up to 70m from the HDBaseT source using one Cat 5e/6/6a cable. VE802 supports RS-232 and IR signaling passthrough, allowing you to control the HDMI source device from the remote unit (VE802R) while also granting access to the HDMI display device from the local unit (VE802T). IR signals can also be extended in both directions. The VE802 features Power over HDBaseT (POH) which can send power over Cat 5e/6/6a cable without an add...
Resolution Support: Up to 1920 x 1200@35 m (Cat 5e/6) / 40 m (Cat 6a); 1080p@60 m (Cat 5e/6) / 70 m (Cat 6a)
Power Supply: VE601R
Connectors: 1 x DC Jack with locking
Consumption: 5 VDC, 4.23 W
VE601T
Connectors: 1 x DC Jack with locking
Consumption: 5 VDC, 1.85 W
Feature: The VE601 DVI HDBaseT-Lite Extender is able to extend a DVI 1080p display up to 70 m using an Ethernet cable. This combination of ATEN and HDBaseT technology even supports sharing 1920 x 1200 media up to 40 m away, offering a simple, adaptable, and cost-effective solution for any professional A/V installation.
The VE601 DVI HDBaseT-Lite Extender is the perfect solution for professional A/V installations that require video signal interference protection, such as in medical and military installations. With its lightweight and easy-to-mount design, not to me...
