Habey HB-VD904 Broadcom Crystal HD PCI express Mini Card AVC/VC-1/H.264 Enhanced Hardware Decoder/Accelerator - OEM
- PCIe mini Card form factor for mobile application
- Full HD video hardware decoding
- Supports multi-standard HD video formats
- Built-in media security functions
- Support H.264, VC-1, MPEG-2, W
Specs
Reviews (19)
Any questions? Our AI mode will help you find out quickly.
Try me now
Learn more about the Habey HB-VD904
| Brand | Habey |
|---|---|
| Model | HB-VD904 |
| Specifications | Interface Mini-PCIe, One-lane PCIe host interface Module format PCIe mini card Decoding Hardware VC-1 Support Complies with the SMPTE 421M-2006 specification Supports Advanced Profile Level 3 with a 40 Mbps maximum encoded bit-rate restriction. Supports Simple and Main Profile (WMV9, WMV-HD) decoding H.264 Support Complies with the ISO/IEC 14496-10 specification Support for AVC High Profile streams up to Level 4.1 with a 40 Mbps maximum encoded bit-rate restriction I, B, and P slices CABAC and CAVLC entropy decoding Field/frame and picture adaptive decoding Macroblock adaptive field/frame decoding All intrablock and interblock sizes Supports Simple and Main Profile decoding MPEG-2 Support Complies with the ISO/IEC 13818-2 specification Supports the Main Profile up to High Level at 125 Mbps HD Standard Support H.264/AVC HP at L 4.1 1080i/1080p, 40 Mbps H.264/AVC HP at L 3.0 480i/480p H.264/AVC HP at L 3.2 720p SMPTE VC-1 AP at L 3 1080i/1080p, 40 Mbps WMV9 (VC-1 SP and MP) MPEG-2 MP at ML MPEG-2 MP at HL Uncompressed Video Output YUV 4:2:0, YUV 4:2:2 NV12 planar YCbCr format YUY2, UYVY-packed YCbCr format QVGA to full HD support Dimensions (W x D x H) 2.0" x 1.18" |
|---|
| Features | PCIe mini Card form factor for mobile application Full HD video hardware decoding Supports multi-standard HD video formats Built-in media security functions Support H.264, VC-1, MPEG-2, WMV decoding up to 1080p Low power consumption |
|---|
| First Listed on Newegg | June 30, 2010 |
|---|
