Honeywell MK3780-61A38 Metrologic MS3780 Fusion Barcode Scanner - Non-Cancelable/Non-Returnable
- 1D Omnidirectional Laser
- USB Kit
- Includes USB cable, and stand
- Maximum Scan Resolution: 5 mil
- Color: Dark gray
+
+
Overview
Specs
Reviews (2)
Any questions? Our AI beta will help you find out quickly.
Try me now
Fusion 3780 Handheld/Hands-Free Scanner
The Fusion™ 3780 laser barcode scanner is ideal for medium-volume retailers. It combines omnidirectional and single-line laser scanning into a lightweight, ergonomic handheld device that’s also affordable. And the scanner's automatic stand detection lets you seamlessly switch from handheld to hands-free presentation scanning on the fly.
Primary Omnidirectional Scan Pattern
Aggressive scanning of barcodes in any orientation, increasing throughput.
Secondary Single-Line Scan Pattern
With the push of a button, switch to a targeted single-line for menu scanning.
Automatic Stand Detection
Hands-free operation for presentation scanning, reducing operator fatigue.
Sleep Mode With IR Wake-Up
Multiple sleep modes reduce power consumption, extending life and lowering your total cost of ownership.
Optional Integration of RF EAS Antenna
Increases efficiency by simulteneously deactivating RF EAS tags and decoding barcodes.
Fusion 3780
Omnidirectional Laser Scanner
Honeywell’s FusionTM 3780 is an affordable hand-held omnidirectional laser scanner with single-line capability that increases retail checkout system efficiency with its automatic in-stand operation, optionally integrated EAS, and industry-leading scan performance.
Fusion combines omnidirectional and single-line laser bar code scanning into a lightweight, ergonomic hand-held form factor. The 20-line scan pattern provides superior scanning over existing singleline hand-held scanners making Fusion ideal for medium-volume retailers including specialty stores, pharmacies, liquor stores, and convenience stores.
An adjustable stand with 50° of tilt and three locking positions provides flexibility for the user to position the scanner for individual comfort and optimal performance. Stabilized with a weighted metal base, the stand may also be hard-mounted to counters or walls.
Fusion also includes CodeGate®, a Honeywell patented feature used in the highly successful Voyager® series. An integrated infra-red (IR) sensor automatically activates the laser when a bar code is present. The user then properly aligns the bar code before pressing the button, transmitting the data to the host. This feature provides the ability to pass over other bar codes, selecting only the required code. No other scanner offers this much control.
Standard features such as Flash ROM, MetroSelect® and MetroSet®2 programming, and user replaceable cables protect your investment by enabling Fusion to grow with you and your application requirements.
Features
- Primary Omnidirectional Scan Pattern: Aggressive scanning in any orientation, increasing throughput
- Secondary Single-Line Scan Pattern: With a push of a button, switch to a targeted single-line for menu scanning applications
- Automatic In-Stand Detection: Hands-free operation for presentation scanning reduces operator fatigue
- Sleep Mode With IR Wake Up: Multiple sleep modes reduce power consumption, extending life and lowering cost of operation
- Optional Integration of RF EAS Antenna: Increases efficiency by simultaneously deactivating RF EAS tags and decoding bar codes
Fusion 3780 Technical Specifications
| Mechanical | ||||
| Dimensions (LxWxH) | 189 mm x 65 mm x 73 mm (7.4? x 2.6? x 2.9?) | |||
| Weight | 195 g (6.9 oz) | |||
| Electrical | ||||
| Input Voltage | 5 VDC ± 0.25 V | |||
| Operating Power | 1.4 W (275 mA @ 5 V) | |||
| Standby Power | 1.0 W (200 mA @ 5 V) | |||
| Host System Interfaces | USB, RS232, Keyboard Wedge, IBM 46xx (RS485), OCIA | |||
| Environmental | ||||
| Operating Temperature | -20°C to 40°C (-4°F to 104°F) | |||
| Storage Temperature | -40°C to 60°C (-40°F to 140°F) | |||
| Humidity | 5% to 95% relative humidity, non-condensing | |||
| Drop | Designed to withstand 1.5 m (5´) drops | |||
| Environmental Sealing | Sealed to resist airborne particulate contaminants | |||
| Light Levels | 4842 Lux | |||
| Scan Performance | ||||
| Scan Pattern | Omnidirectional: 5 fields of 4 parallel lines; Button activated single line | |||
| Scan Speed | Omnidirectional: 1,333 scan lines per second; Single line: 67 scan lines per second | |||
| Print Contrast | 35% minimum reflectance difference | |||
| Pitch, Skew | 60°, 60° | |||
| Decode Capabilities | Reads standard 1D and GS1 DataBar symbologies | |||
| Warranty | 3 year factory warranty | |||
Metrologic Fusion combines omni directional and single-line laser bar code scanning into a lightweight, ergonomic hand-held form factor. The 20-line scan pattern provides superior scanning over existing single-line scanners making Fusion ideal for medium-volume retailers including specialty stores, pharmacies, liquor stores, and convenience stores. An adjustable stand with three locking positions provides flexibility for the user to position the scanner for individual comfort and optimal performance. Stabilized with a weighted metal base, the stand may also be hard-mounted to counters or walls. Host Interface: Multi-interface Barcode Symbology Supported: All Standard 1D Symbologies RSS-Expanded RSS-14 RSS-Limited Package Contents: Fusion MS3780 Barcode Scanner MS3780 User's Guide MetroSelect Configuration Guide Host Interface: Multi-interface Product Type: Handheld Barcode Scanner Product Type: Handheld Barcode Scanner Manufacturer Part Number: MK3780-61A38 Limited Warranty: 1 Year Weight (Approximate): 6.90 oz Color: Gray Connectivity Technology: Cable Color: Gray Connectivity Technology: Cable Manufacturer: Honeywell International, Inc Product Model: MS3780 Product Name: Fusion MS3780 Bar Code Reader Product Line: Fusion Brand Name: Honeywell Light Source: Laser Brand Name: Honeywell Light Source: Laser Height: 2.9 Width: 2.6 Depth: 7.4 Scan Pattern: Omni-directional Scan Pattern: Single Line Product Family: Fusion
