| Features | Motion Tolerance: Up to 584.00 cm (230.00")/second
Symbol Contrast: 20% minimum reflectance
Symbology/X-Dim Typical Range: 100% UPC 44.00 mm to 552.00 mm (1.70" to 21.70") 10 mil Code 39 65.00 mm to 544.00 mm (2.60" to 21.40") 20 mil Code 39 49.00 mm to 812.00 mm (1.90" to 32.00") 10 mil DataMatrix 113.00 mm to 275.00 mm (4.40" to 10.80") 6.7 mil PDF417 120.00 mm to 225.00 mm (4.70" to 8.90")
Operating Temperature: -20 to 50 degrees Celsius (-4 to 122 degrees Fahrenheit)
Storage Temperature: -20 to 60 degrees Celsius (-4 to 140 degrees Fahrenheit)
Humidity: 0% to 95% relative humidity (non-condensing)
Tumble: 2,000 0.5 meter (1.6 ft) tumbles
Environmental Sealing: IP54
Light Levels: 0 to 100,000 lux
ESD: +/- 20 kV air discharge, +/- 10 kV contact discharge
Radio Range: 2.4 GHz to 2.5 GHz (ISM Band) Adaptive Frequency Hopping Bluetooth v. 4.1: Class 1; 100 m (330 ft) line of sight; NFC communications to simplify pairing Advanced: Bluetooth above plus Wi-Fi 802.11 a/b/g/n/ac
Number of Scans: Slim Battery Version: 3,000 over 8-hour shift Extended Battery Version: 8,000 over 10-hour shift
Expected Charge Time: 4 hours
Wearable Accessories: Two-Finger Ring Strap 8680i505FNGRSTRAP Triggered Ring- Strap Mount 8680i505RINGMT Glove Mount Coming Q3 2018 8680i505GMT Glove, XL Coming Q3 2018 8680i505RHGXL Glove, L Coming Q3 2018 8680i505RHGL Glove, M Coming Q3 2018 8680i505RHGM Glove, S Coming Q3 2018 8680i505RHGS Glove, L LH Coming Q3 2018 8680i505LHGL Glove, M LH Coming Q3 2018 8680i505LHGM
Charging and Batteries: 4-Bay Battery Charger MB4-BAT-SCN02 4-Bay Device Charger MB4-SCN02 Extended Battery BAT-SCN02 Slim Battery BAT-SCN03 Power Cable 19-19726 Power Cable 19-19729 Power Cable 77900507E |
|---|
