International version HPE Aruba AP-515 (RW) - wireless access point Q9H62A
- International version AP-515 (RW)
- Q9H62A
- Manufacturer: HPE
- Product Type: Wireless Access Point
- Applicable Country: Rwanda
- Wireless LAN Standard: 802.11ax
- Bluetooth Standard: Bluetooth 5
- Frequency Band: 2.40 GHz, 5 GHz
- Number of Internal Antennas: 4
- Wireless Transmission Speed: 5.40 Gbit/s
- MIMO Technology: Yes
- Beamforming Technology: Yes
- Ethernet Technology: 2.5 Gigabit Ethernet, Gigabit Ethernet
- Number of Network (RJ-45) Ports: 2
- PoE PD Port: Yes
- USB: Yes
- Management Port: Yes
- Form Factor: Ceiling Mountable,Wall Mountable,Rail-mountable
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
International version HPE Aruba AP-515 (RW) - wireless access point Q9H62A.
Aruba Q9H62A AP-515 (RW) Dual Radio 4x 4:4 + 2x 2:2 802.11 ax Internal Antennas Unified Campus AP, Support WIFI6
AP-515: Four integrated dual-band downtilt omni-directional antennas for 4x4 MIMO with peak antenna gain of 4.2 dBi in 2.4GH z and 7.5 dBi in 5GHz. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.
- Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the effective per-antenna pattern is 3.8 dBi in 2.4GH z and 4.6 dBi in 5GHz.
5GHz radio:
Four spatial stream Single User (SU) MIMO for up to 4.8G bps wireless data rate to individual 4SS HE160 802.11 ax client devices (max)
Two spatial stream Single User (SU) MIMO for up to 1.2G bps wireless data rate to individual 2SS HE80 802.11 ax client devices (typical)
Four spatial stream Multi User (MU) MIMO for up to 4.8G bps wireless data rate to up to four 1SS or two 2SS HE160 802.11 ax DL-MU-MIMO capable client devices simultaneously (max)
Four spatial stream Multi User (MU) MIMO for up to 2.4G bps wireless data rate to up to four 1SS or two 2SS HE80 802.11 ax DL-MU-MIMO capable client devices simultaneously (typical)
2.4GH z radio:
Two spatial stream Single User (SU) MIMO for up to 574Mbps wireless data rate to individual 2SS HE40 802.11 ax client devices or to two 1SS HE40 802.11 ax DL-MU-MIMO capable client devices simultaneously (max)
Two spatial stream Single User (SU) MIMO for up to 287Mbps wireless data rate to individual 2SS HE20 802.11 ax client devices or to two 1SS HE20 802.11 ax DL-MU-MIMO capable client devices simultaneously (typical)
Support for up to 512 associated client devices per radio, and up to 16 BSSIDs per radio
Aruba Q9H62A AP-515 (RW) Dual Radio 4x 4:4 + 2x 2:2 802.11 ax Internal Antennas Unified Campus AP, Support WIFI6
AP-515: Four integrated dual-band downtilt omni-directional antennas for 4x4 MIMO with peak antenna gain of 4.2 dBi in 2.4GH z and 7.5 dBi in 5GHz. Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The downtilt angle for maximum gain is roughly 30 degrees.
- Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the effective per-antenna pattern is 3.8 dBi in 2.4GH z and 4.6 dBi in 5GHz.
5GHz radio:
Four spatial stream Single User (SU) MIMO for up to 4.8G bps wireless data rate to individual 4SS HE160 802.11 ax client devices (max)
Two spatial stream Single User (SU) MIMO for up to 1.2G bps wireless data rate to individual 2SS HE80 802.11 ax client devices (typical)
Four spatial stream Multi User (MU) MIMO for up to 4.8G bps wireless data rate to up to four 1SS or two 2SS HE160 802.11 ax DL-MU-MIMO capable client devices simultaneously (max)
Four spatial stream Multi User (MU) MIMO for up to 2.4G bps wireless data rate to up to four 1SS or two 2SS HE80 802.11 ax DL-MU-MIMO capable client devices simultaneously (typical)
2.4GH z radio:
Two spatial stream Single User (SU) MIMO for up to 574Mbps wireless data rate to individual 2SS HE40 802.11 ax client devices or to two 1SS HE40 802.11 ax DL-MU-MIMO capable client devices simultaneously (max)
Two spatial stream Single User (SU) MIMO for up to 287Mbps wireless data rate to individual 2SS HE20 802.11 ax client devices or to two 1SS HE20 802.11 ax DL-MU-MIMO capable client devices simultaneously (typical)
Support for up to 512 associated client devices per radio, and up to 16 BSSIDs per radio
