HUBBELL WIRING DEVICE-KELLEMS GFR20W GFCI Receptacle, Duplex, 1 Phase, NEMA

The HUBBELL GFCI Receptacle is a 20A, 125VAC duplex outlet suitable for use in industrial and commercial environments. It features AUTOGUARD® self-test technology; rated to monitor ground fault protection capability at regular intervals (every 30 seconds). The device is rated to disconnect power when it detects loss of GFCI protection or damage to certain internal components. Visual indicators on the face display power status, trip condition, ground fault detection, and end-of-life notifications. The receptacle does not supply power when reverse wiring is detected.

Key Features of the HUBBELL GFCI Receptacle:

• Amperage/Voltage: Rated for 20A at 125V AC


• NEMA Configuration: 5-20R decorator duplex outlet


• Self-Testing: Rated to test GFCI function at regular intervals (every 30 seconds)


• Indicators: Visual signals for power status, trip condition, ground fault detection, and end-of-life


• Protection Response: Rated to disconnect power when unable to provide GFCI protection or upon detection of incorrect line/load wiring


• Mounting Type: Flush mount with included mounting hardware; single gang configuration


• Wiring Method: Accepts both back and side screw terminal connections; polarized design with grounding feature


• Contact Material/Housing: Brass contacts with nylon housing suitable for general use in industrial/commercial settings
