  6. Item#: 9SIBM9SJWV9948

Out of stock
This item is currently out of stock and it may or may not be restocked.
Out of Stock
Ships from China.
Most customers receive within 7-9 days.
Add to wish list
Sold by NUC PC Store
Hot Seller
4.5 (26 seller ratings)

Shipped by NUC PC Store

Shop it at NeweggBusiness.

Meet Your Seller

NUC PC Store
Shop All Intel Products | Visit NUC PC Store
FOLLOW

Intel Dragon Canyon NUC 12 Extreme RNUC12DCMi90001 Mini Gaming Computer Barebone w/ US Cord (Intel Core i9-12900,Intel Z690, 2x Thunderbolt™ 4 ) supports 12'' max video card length, w/o graphic card

(6)(4) Write a Review
  • Intel Core i9-12900 Processor
  • Intel Z690
  • 2 x 260Pin SO-DIMM DDR4 3200
  • Intel UHD Graphics 770
  • 2x Thunderbolt™ 4
  • 2x M.2 PCIe X4 Gen4 slots (PCH), M.2 PCIe X4 Gen4 slots (CPU); Double-wide PCIe X16 Gen5 (CPU) slot, 12" max card length
Specs
Reviews (6)
See all Q & A

Learn more about the Intel RNUC12DCMi90001

General
Brand Intel
Series NUC 12 Extreme
Model RNUC12DCMi90001
CPU Supported
CPU Installed Intel Core i9-12900 Processor (30M Cache, up to 5.10 GHz)
Chipset
North Bridge Intel Z690
Memory Supported
Memory installed No Memory
Memory slot 2 x 260Pin SO-DIMM
Memory Type Supported DDR4 3200
Max Memory Supported 64GB
Dual Channel Memory Supported Yes
Expansion Slots
PCI Express 1 x PCI Express 5.0 x16
Storage
Hard Drive Installed No Hard Drive
Serial ATA 2 x SATA 6.0Gb/s
M.2 2 x M.2 PCIe X4 Gen4 slots (PCH)
1 x M.2 PCIe X4 Gen4 slots (CPU)
Graphics
Onboard Video Intel UHD Graphics 770
Audio
Channel 7.1-CH
Communications
First LAN 10GbE (AQC113)
Second LAN Intel i225-LM
Wireless LAN Intel Wi-Fi 6E AX211
Bluetooth Bluetooth v5.2
Max LAN Speed 10GbE + 2.5GbE
Front Panel Ports
Front USB USB 3.2g2 Type-A and Type-C
Card Reader SDXC with UHS-II support
Back Panel Ports
HDMI HDMI 2.0b
Rear USB 6 x USB 3.2g2, 2 x TB4 (USB 3.2g2)
Physical SPEC
Dimensions 7.44" x 4.72" x 14.00"
Features
Features 12th Gen Intel Core i9/i7 processors

PCIe x16 Gen5 slot for add-in discrete graphics (up to 12" in length)

Up to 64GB dual-channel DDR4-3200 SODIMMs

3 M.2 key M slots

HDMI 2.0b connector

2 Thunderbolt 4 ports

6 USB 3.2 Gen2 Type-A connectors

Intel Wi-Fi 6E AX211

10Gb Ethernet port standard; and additional 2.5Gb Ethernet port on Intel Core i9 processor SKU
Additional Information
First Listed on Newegg May 25, 2023

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Please contact the Seller directly for warranty information. Warranty information may also be found on the Manufacturer's website.
  • Read full details
  • CONTACT

Return Policies

  • Return for refund within: 30 days
  • Return for replacement within: non-replaceable
  • This item is covered by NUC PC Store Return Policy
