iStarUSA D-260HNBK-C246-1 2U Rackmount Server Barebone - Black LGA 1151 Intel C246
- LGA 1151
- Supports Intel Xeon E-2100 Processors
- 4 x 288Pin Memory Slots
- 500W Single
+
+
Learn more about the iStarUSA Inc. D-260HNBK-C246-1
| Brand | iStarUSA |
|---|---|
| Model | D-260HNBK-C246-1 |
| Form Factor | 2U Rackmount |
| Material | Zinc-Coated Steel |
| Workload | Edge Server |
| CPU Type | Supports Intel Xeon E-2100 Processors |
|---|---|
| CPU Socket | LGA 1151 |
| North Bridge | Intel C246 |
|---|
| Memory Slots | 4 x 288Pin |
|---|---|
| Installed Memory Size | No Memory Installed |
| Max Memory Supported | 64GB |
| Channel Supported | Dual Channel |
| ECC Supported | Yes |
| Registered | No |
| Serial ATA | 8 x SATA 600 |
|---|
| PCI Express | 1 x PCIe 3.0 x16 1 x PCIe 3.0 x8 1 x PCIe 3.0 x4 |
|---|
| First LAN | 2 x RJ45 GLAN by Intel® i210&I219LM |
|---|---|
| Max. LAN Speed | 1 Gigabit |
| 3.5" Bays | 1 |
|---|---|
| Hot-Swap Bays | 6 |
| COM | 1 |
|---|---|
| VGA | 1 |
| Rear USB | 4 x USB 3.0 |
| RJ45 | 2 |
| Other Ports | 1 x HDMI, 1 x DisplayPort |
| Max. Power | 500W Single |
|---|
| Features | 2U Rackmount with 500W PSU 6 x 3.5" Trayless Hot-Swappable Drive Bays Supports Intel Xeon E-2100 Processors Supports Dual channel DDR4 2666/2400 ECC and non-ECC U DIMM max 64 GB Support 8x SATA3 by C246 Supports 1x PCIe 3.0 x16, 1x PCIe 3.0 x8, 1x PCIe 3.0 x4 Supports Intel i210&i219LM Supoorts 4 x Half Height Expansion Slot |
|---|
| Dimensions | 3.48" x 20.66" x 19.00" |
|---|---|
| Weight | 30.00 lbs. |
| First Listed on Newegg | May 11, 2020 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 1 year
- Read full details
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.com's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-888-989-1189
- Support Email: tech@istarusa.com
- Support Website
- View other products from iStarUSA Inc.
LOADING...
The iStarUSA D-260HNBK-C246-1 is a 2U rackmount server barebone for edge-server builders, with support for Intel Xeon E-2100 processors, up to 64GB of dual-channel ECC or non-ECC memory, and six trayless hot-swap drive bays.
Recommended For
- Home-lab and small-office builders who want a rackmount file server or NAS with six front-access hot-swap drive bays for storage and backup workflows.
- Rack-based media-server or HTPC builders who want a compact 2U system that can be installed in a rack or used in a desktop orientation.
- Small-server operators who need an entry-level Xeon E-2100/C246 platform with ECC memory support for a single-socket server workload.
- Administrators who value quick drive replacement and straightforward SATA storage expansion, with six hot-swap bays and eight SATA ports listed for the system.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Edge server deployments needing Intel Xeon E-2100 processor support, hot-swappable drive bays, and dual-channel ECC memory capability |
| Processor And Platform | LGA 1151 socket with Intel C246 chipset; supports Intel Xeon E-2100 processors |
| Memory Configuration | Four 288-pin slots support up to 64GB of dual-channel DDR4 2666/2400 memory; ECC and non-ECC unbuffered DIMMs supported; no memory installed |
| Storage And Drive Bays | Eight SATA 600 ports and six 3.5-inch trayless hot-swappable drive bays |
| Expansion | One PCIe 3.0 x16, one PCIe 3.0 x8, and one PCIe 3.0 x4 slot; supports four half-height expansion slots |
| Networking | Two Intel i210/i219LM Gigabit Ethernet ports with speeds up to 1Gbps |
| Ports And Video | Four rear USB 3.0 ports, one COM port, one VGA port, one HDMI port, and one DisplayPort |
| Power | 500W single power supply |
| Chassis And Dimensions | 2U rackmount chassis made of zinc-coated steel; 3.48 × 20.66 × 19.00 inches and 30 lb |
| Model Identifiers | iStarUSA D-260HNBK-C246-1 |
