iStarUSA D-260HNBL-C246-1 2U Rackmount Server Barebone - Blue LGA 1151 Intel C246
- LGA 1151
- Supports Intel Xeon E-2100 Processors
- 4 x 288Pin Memory Slots
- 500W Single
+
+
Learn more about the iStarUSA Inc. D-260HNBL-C246-1
| Brand | iStarUSA |
|---|---|
| Model | D-260HNBL-C246-1 |
| Form Factor | 2U Rackmount |
| Material | Zinc-Coated Steel |
| Workload | Edge Server |
| CPU Type | Supports Intel Xeon E-2100 Processors |
|---|---|
| CPU Socket | LGA 1151 |
| North Bridge | Intel C246 |
|---|
| Memory Slots | 4 x 288Pin |
|---|---|
| Installed Memory Size | No Memory Installed |
| Max Memory Supported | 64GB |
| Channel Supported | Dual Channel |
| ECC Supported | Yes |
| Registered | No |
| Serial ATA | 8 x SATA 600 |
|---|
| PCI Express | 1 x PCIe 3.0 x16 1 x PCIe 3.0 x8 1 x PCIe 3.0 x4 |
|---|
| First LAN | 2 x RJ45 GLAN by Intel® i210&I219LM |
|---|---|
| Max. LAN Speed | 1 Gigabit |
| 3.5" Bays | 1 |
|---|---|
| Hot-Swap Bays | 6 |
| COM | 1 |
|---|---|
| VGA | 1 |
| Rear USB | 4 x USB 3.0 |
| RJ45 | 2 |
| Other Ports | 1 x HDMI, 1 x DisplayPort |
| Max. Power | 500W Single |
|---|
| Features | 2U Rackmount with 500W PSU 6 x 3.5" Trayless Hot-Swappable Drive Bays Supports Intel Xeon E-2100 Processors Supports Dual channel DDR4 2666/2400 ECC and non-ECC U DIMM max 64 GB Support 8x SATA3 by C246 Supports 1x PCIe 3.0 x16, 1x PCIe 3.0 x8, 1x PCIe 3.0 x4 Supports Intel i210&i219LM Supoorts 4 x Half Height Expansion Slot |
|---|
| Dimensions | 3.48" x 20.66" x 19.00" |
|---|---|
| Weight | 30.00 lbs. |
| First Listed on Newegg | May 11, 2020 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 1 year
- Read full details
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.com's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-888-989-1189
- Support Email: tech@istarusa.com
- Support Website
- View other products from iStarUSA Inc.
LOADING...
The iStarUSA D-260HNBL-C246-1 is a 2U rackmount server barebone with an Intel C246 chipset, LGA 1151 socket, six trayless hot-swap drive bays, and a 500W power supply, suited to builders creating edge-server or storage systems around compatible Intel Xeon E-2100 processors.
Recommended For
- Small-business or branch-office IT teams building a rackmount server for shared files, backups, or edge workloads that benefit from six hot-swap 3.5-inch drive bays and Xeon E-2100 support.
- Home-lab builders who have rack space and want a customizable server or storage system with trayless hot-swap drive access, rather than a ready-to-run appliance.
- System integrators who need a 2U barebone platform for a tailored Xeon E-2100 build and can select and install the processor, memory, and storage themselves.
- Home-theater or media-server builders who want a rackmount-or-desktop chassis orientation and plan to use the six hot-swap bays for local media storage.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Edge-server deployments needing a 2U rackmount chassis, support for Intel Xeon E-2100 processors, and hot-swappable drive bays |
| Processor And Platform | LGA 1151 socket with Intel C246 chipset; supports Intel Xeon E-2100 processors |
| Memory Configuration | Four 288-pin slots, dual-channel DDR4 2666/2400 U DIMM support, up to 64GB; supports ECC and non-ECC memory; none installed |
| Storage And Drive Bays | Eight SATA 600 ports; six trayless hot-swappable drive bays. The catalog also lists one 3.5-inch bay |
| Expansion | One PCIe 3.0 x16, one PCIe 3.0 x8, and one PCIe 3.0 x4 slot; four half-height expansion slots supported |
| Networking And Connectivity | Two Intel i210/i219LM Gigabit Ethernet RJ45 ports, rated up to 1Gbps; four rear USB 3.0 ports, one COM port, one VGA port, one HDMI port, and one DisplayPort |
| Power | 500W single power supply |
| Chassis And Dimensions | Zinc-coated steel 2U rackmount chassis; 3.48 × 20.66 × 19.00 inches; 30 lb |
| Model Identifiers | iStarUSA D-260HNBL-C246-1 |
