iStarUSA D-313SE-C246-1 3U Intel Xeon E-2100 UP Rackmount Server Barebone
- 3U Rackmount with 500W PSU
- Supports Intel Xeon E-2100 Processors
- Supports Dual channel DDR4 2666/2400 ECC and non-ECC U DIMM max 128 GB
- Support 8x SATA3 by C246
- Supports 1x PCIe 3.0 x16, 1x PCIe 3.0 x8, 1x PCIe 3.0 x4
+
+
Learn more about the iStarUSA Inc. D-313SE-C246-1
| Brand | iStarUSA |
|---|---|
| Model | D-313SE-C246-1 |
| Form Factor | 3U Rackmount |
| Material | Zinc-Coated Steel |
| Workload | Edge Server |
| CPU Type | Supports Intel Xeon E-2100 Processors |
|---|
| North Bridge | Intel C246 |
|---|
| Memory Slots | 4 x U Dimm |
|---|---|
| Max Memory Supported | 128GB |
| Memory Type Supported | Dual channel DDR4 2666/2400 ECC and non-ECC U DIMM max 128 GB |
| Serial ATA | 8x SATA3 6Gb/s (SATA0-7, SATA0 supports SATA DOM, and is shared with M.2(PCIE3.0(x4))/ SATA3) |
|---|
| GPU/VPU | ASPEED AST2500 |
|---|---|
| Video Memory | DDR4 32MB |
| PCI Express | 1x PCIe 3.0 x16 1x PCIe 3.0 x8 1x PCIe 3.0 x4 |
|---|
| Number of LAN | GLAN by Intel i210 Realtek RTL8211E for dedicated management GLAN |
|---|---|
| Max. LAN Speed | 1 Gigabit |
| VGA | 1 |
|---|---|
| Rear USB | 4 x USB 3.0 |
| RJ45 | 3 |
| Other Ports | Internal Connector USB: 1 (supports 2 USB 3.0 ports):: 1 (supports 2 USB 2.0 ports) SATA: 8x SATA3 6Gb/s GPIO: 2 x SGPIO Speaker Header: 1(4pin) TR1_Header: 1 TPM_Header: 1 IPMB_Header: 1 Fan_Header: 3 (1CPU/1Front/1Rear) Buzzer: 1 |
| Features | 3U Rackmount with 500W PSU Supports Intel Xeon E-2100 Processors Supports Dual channel DDR4 2666/2400 ECC and non-ECC U DIMM max 128 GB Support 8x SATA3 by C246 Supports 1x PCIe 3.0 x16, 1x PCIe 3.0 x8, 1x PCIe 3.0 x4 |
|---|
| Dimensions | 5.25" x 16.86" x 19.00" |
|---|---|
| Weight | 27.00 lbs. |
| First Listed on Newegg | October 16, 2019 |
|---|
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 1 year
- Limited Warranty period (labor): 1 year
- Read full details
Return Policies
- Return for refund until: January 31, 2027
- Return for replacement until: January 31, 2027
- This item is covered by Newegg.com's Extended Holiday Return Policy.
- Read full return policy for details.
We want to ensure your holiday shopping this year is hassle-free. That’s why we’re automatically extending our return policies on almost every product! For purchases placed between November 1st, 2026 and December 31, 2026 you will have until January 31, 2027 to return your product.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-888-989-1189
- Support Email: tech@istarusa.com
- Support Website
- View other products from iStarUSA Inc.
LOADING...
The iStarUSA D-313SE-C246-1 is a 3U rackmount server barebone with a 500W power supply, designed for edge-server deployments that need Intel Xeon E-2100 processor support, up to 128GB of memory, and room to configure storage and expansion cards.
Recommended For
- Small-business or lab administrators building a fixed, rack-mounted server who want to choose and install their own compatible Xeon E-2100 CPU, memory, and storage.
- Home-server and small-office NAS builders who need up to eight SATA connections for a multi-drive storage setup and are comfortable assembling a barebone system.
- Users building a storage or compute server who specifically want the option of ECC UDIMM memory and a platform based on Intel’s Xeon E-2100 and C246 generation.
- Rack-based homelab or edge-server builders who need several PCIe expansion slots for a measured set of add-in cards, such as a storage controller or network adapter.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Edge-server deployment in a 3U rackmount chassis with support for Intel Xeon E-2100 processors |
| Processor And Platform | Supports Intel Xeon E-2100 processors on an Intel C246 platform |
| Memory Configuration | Four U DIMM slots support dual-channel DDR4-2666/2400 ECC or non-ECC memory, up to 128 GB |
| Storage And Expansion | Eight SATA3 6 Gb/s connections; SATA0 supports SATA DOM and is shared with the M.2 PCIe 3.0 x4/SATA3 connection. Expansion slots include one PCIe 3.0 x16, one x8, and one x4 |
| Networking | Intel i210 Gigabit LAN and dedicated Realtek RTL8211E management LAN, with three RJ45 ports and up to 1 Gigabit LAN speed |
| Graphics And Video | ASPEED AST2500 graphics with 32 MB DDR4 video memory and one VGA output |
| Ports And Internal Headers | Four rear USB 3.0 ports; internal headers support two USB 3.0 and two USB 2.0 ports. Also includes SGPIO, speaker, TR1, TPM, IPMB, and three fan headers, plus a buzzer |
| Power Supply | 500 W power supply |
| Chassis And Dimensions | 3U rackmount chassis made of zinc-coated steel; 5.25 × 16.86 × 19.00 inches and 27 lb |
| Model Identifiers | iStarUSA D-313SE-C246-1 |
