Jetway JNF99FL-525-LF Fanless Intel Atom D525, 6*SATA2, Dual Intel GbLAN, Mini-ITX MB
- Intel Atom
- DDR3 1066
Specs
Reviews (16)
Learn more about the JETWAY JNF99FL-525-LF
| Brand | JetWay |
|---|---|
| Model | JNF99FL-525-LF |
| Combo Type | Motherboard / CPU Combo |
| CPU | Intel Atom D525 (1.8GHz, Dual-Core) |
|---|---|
| With Cooler | Yes |
| CPU Type | Intel Atom |
|---|
| South Bridge | Intel ICH9R |
|---|
| Number of Memory Slots | 2x204pin SO-DIMM |
|---|---|
| Memory Standard | DDR3 1066 |
| Maximum Memory Supported | 4GB |
| PCI Slots | 1 x PCI Slot |
|---|---|
| Mini Card Slots | 1 x Mini PCIe |
| Other Slots | Onboard 18-bit single channel LVDS connector |
| SATA | 6 x SATA 3.0Gb/s |
|---|---|
| SATA RAID | 0/1/5/10 |
| Audio Chipset | VIA VT1705 |
|---|---|
| Audio Channels | 6 Channels |
| LAN Chipset | Intel 82574L |
|---|---|
| Second LAN Chipset | Intel 82574L |
| Max LAN Speed | 2 x 1Gbps |
| PS/2 | 1 x PS/2 keyboard/mouse port |
|---|---|
| COM | 1 |
| Video Ports | D-Sub |
| USB 1.1/2.0 | 3 x USB 2.0 |
| USB 3.0 | 2 x USB 3.0 |
| Audio Ports | 3 Ports |
| Onboard USB | 6 x USB 2.0 |
|---|
| Features | Dual Intel Gigabit LAN Jetway Daughter Board Compatible Support Watchdog Technology |
|---|
| Form Factor | Mini ITX |
|---|---|
| Dimensions (W x L) | 6.7" x 6.7" |
| Date First Available | June 22, 2011 |
|---|
