Lantronix EDS00812N-01 8-Port Device Server

Be the first to review this product...

8 x RJ-45 , 1 x RJ-45

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

The EDS8PR is the first line of rack mountable device server capable of delivering an data center-grade, programmable device computing and networking platform for integrating "edge" equipment into the enterprise network.

MAIN OVERVIEW FEATURES: Ethernet Technology: Fast EthernetNetwork (RJ-45): YesNumber of Network (RJ-45) Ports: 9Form Factor: Wall Mountable,Rack-mountableHeight: 1.75" (44.45 mm)Width: 17.25" (438.15 mm)Depth: 12" (304.80 mm)Weight (Approximate): 4.54 kgPackage Contents: EDS8PR 8-Port Device ServerDeviceInstaller configuration softwareCom Port Redirector software and related utilitiesLimited Warranty: 2 Year

Model
Brand	Lantronix
Model	EDS00812N-01

Details
Type	Consumer Electronics

Features
Features	EDS8PR multi-port, secure device server; 1U, 8-port, 100-240 VAC Dimensions (LxWxH): 12" x 17.25" x 1.75" Weight: 4.54 Kg (10 lbs.) CPU : Intel XScale IXP420 Network Processor running at 266MHz 32k Instruction Cache 32k Data Cache Memory: 64 MB SDRAM 8 MB Flash 2 KB EEPROM Indicators (LED): 10Base-T and 100Base-TX Link Ethernet Activity Serial Transmit Data Serial Receive Data Power Diagnostics Connector: RJ45 Standards: HTTP, HTTPS, FTP, TFTP, Telnet, TCP, UDP,LPD, XML, DHCP, SSHv2, SSLv3, SNMPv2, AutoIP, RSS, ARP, ICMP, SYSLOG, AES, SMTP, DNS, BOOTP, Traceroute Management: Internal web server, SNMP v2 (MIBII,RS232MIB), Serial login, Telnet login, XML Firmware: Upgradable via the Web Manager, TFTP or FTP Internal Web Server: Serves static and dynamic CGI-based pages and applets Storage capacity: 6 MB using industry-standard file system Operating: 0° to +50°C (32° to 122°F) Storage: -40° to 70°C (-40 to 151°F) Relative Humidity: 5 to 95%, non-condensing Power: 100-240VAC, 50 to 60 Hz IEC-type cord 20 Watts Security: SSL v3, SSH v2 MD5, SHA-1 Rijndael/AES 128-bit encryption 3DES encryption ARC4 128-bit encryption Password protection IP address filtering Hardened OS and stack

Additional Information
First Listed on Newegg	February 11, 2011
