    MagTek 21040104 USB HID Swipe Reader

    • ISO 7810 and ISO 7811/AAMVA
    • USB-HID
    • Track 1 & 2
    This item is covered under the Manufacturer Only Return Policy.
    +
    +
    Overview
    Specs
    Reviews (1)
    See all Q & A

    Any questions? Ask CelesteSM will help you find out quickly.

    MiniUSB

    MagTek MiniUSB Stripe Credit Card Reader

    MiniUSB
    • Powered USB bus–no external power supply required.
    • Hardware compatible with any computer or terminal with an USB interface
    • Single, dual or three track capability
    • Bi-directional read capability
    • Reads encoded cards that meet ISO/ANSI/CDL/AAMVA standards
    • Up to 1,000,000 passes with ISO-conforming cards
    • Includes USB interface cable
    • This device does NOT use keyboard emulation
    OPERATING
    Reference Standards: ISO, ANSI, CDL and AAMVA
    Power Input: From USB
    Recording Method: Two-frequency coherent phase (F2F)
    Message Format: Vendor defined emulation
    Card Speed: 3 to 50 IPS
    MTBF: Electronics: 125,000 hours
    Head: 1,000,000 passes
    MECHANICAL
    Dimensions: Length: 3.94" (100mm)
    Width: 1.28" (32,5mm)
    Height: 1.23" (31,3mm)
    Weight: Reader with cable: 5.8 oz. (1,65g)
    Connector: USB
    ENVIRONMENTAL
    Temperature: Operating: 32ºF to 131ºF (0ºC to 55ºC)
    Storage: -22ºF to 158ºF (-30ºC to 70ºC)
    Humidity: Operating: 10% to 90% noncondensing
    Storage: Up to 100% noncondensing
    Altitude: Operating: 0-10,000 ft. (0-3,048m)
    Storage: 0-50,000 ft. (0-15,240m)
    MagTek 21040104. Brand New. . Product # 21040104. . . . . Packaged Quantity: 1. Magnetic Stripe Track Configuration: Dual Track. Magnetic Stripe Track Number: Track 1. Magnetic Stripe Track Number: Track 2. USB: Yes. .

    Warranty & Returns

    Warranty, Returns, And Additional Information

    Warranty

    • Limited Warranty period (parts): 1 year
    • Limited Warranty period (labor): 1 year
    • Read full details

    Return Policies

    LOADING...
    LOADING...

    The MagTek 21040104 is a USB-HID magnetic-stripe reader for businesses and system integrators who need to read Track 1 and Track 2 cards on a compatible PC or USB-equipped terminal, using the standard Windows HID driver without a third-party device driver.

    Recommended For

    • Developers building Windows-based card-reading applications who want a USB HID magstripe reader that their software can communicate with directly, rather than a reader that types card data like a keyboard.
    • POS and kiosk integrators adding magnetic-stripe reading to a fixed workstation, where the host application is set up to receive data from a vendor-defined USB HID device.
    • Organizations developing membership, loyalty, identification, or similar systems that need to read Track 1 and 2 magnetic-stripe cards in either swipe direction.
    • IT teams deploying readers at desks or counters who want USB connection and standard Windows HID communications without installing a third-party device driver.

    Spec Summary

    AttributeValue
    Best ForReading Track 1 and 2 magnetic-stripe cards on USB-equipped computers or terminals
    Card Reading And FormatsReads Track 1 and 2 cards in ISO 7810 and ISO 7811/AAMVA formats, with bidirectional reading at 3 to 60 IPS
    Connectivity And SetupUSB-HID connection with a built-in 6-foot USB cable; compatible with PCs, computers, and terminals with a USB interface, using the standard Windows HID driver without a third-party device driver
    Configuration And StatusLED status indicator, programmable USB serial number descriptor and interrupt-in endpoint polling interval, and non-volatile configuration memory
    Physical SpecificationsBlack; 3.94 × 1.28 × 1.23 inches (L × W × H); 4.5 oz. (127.57 g)
    Power5 V
    Model IdentifiersMagTek 21040104
