METRA RAP-BW-8590 BMW 1990-2002 Turbowire Harness (708590)
- Metra
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Raptor BW-8590 Same as Metra 70-8590 Wiring Harness for Select BMW 1990-2002
Brand: Raptor
MPN: BW-8590
Condition: New
-17-pin plug
-Plugs into car harness at radio
-For non-amplified vehicles only
-Power/4 Speaker
-For select 1990-2002 BMW Vehicles
-Allows for the installation of an aftermarket radio using the existing factory wiring and connectors
-No cutting of factory wiring is needed
SPECIFICATIONS:
Wire Connections
Yellow – 12V Constant
Red – 12V Accessory
Black - Ground
Orange – Dash Light Dimmer/Illumination
Green – Left Rear Speaker (+)
Green with Black Stripe Left Rear Speaker (-)
White – Left Front Speaker (+)
White with Black Stripe – Left Front Speaker (-)
Purple – Right Rear Speaker (+)
Purple with Black Stripe – Right Rear Speaker (-)
Gray – Right Front Speaker (+)
Gray with Black Stripe – Right Front Speaker (-)
Brand: Raptor
MPN: BW-8590
Condition: New
-17-pin plug
-Plugs into car harness at radio
-For non-amplified vehicles only
-Power/4 Speaker
-For select 1990-2002 BMW Vehicles
-Allows for the installation of an aftermarket radio using the existing factory wiring and connectors
-No cutting of factory wiring is needed
SPECIFICATIONS:
Wire Connections
Yellow – 12V Constant
Red – 12V Accessory
Black - Ground
Orange – Dash Light Dimmer/Illumination
Green – Left Rear Speaker (+)
Green with Black Stripe Left Rear Speaker (-)
White – Left Front Speaker (+)
White with Black Stripe – Left Front Speaker (-)
Purple – Right Rear Speaker (+)
Purple with Black Stripe – Right Rear Speaker (-)
Gray – Right Front Speaker (+)
Gray with Black Stripe – Right Front Speaker (-)
