Zebra (Motorola) LI2208-SR7U2100AZN LI2208 Barcode Scanner, Black with USB Cable
- Captures 1D Barcode on Screens and Displays
- USB Cable Included
- Black
+
+
Overview
Specs
Reviews (2)
See all Q & A
Any questions? Ask CelesteSM will help you find out quickly.
Try me now
Motorola LI2208 Barcode Scanner
Whether your workers are scanning bar codes printed on paper labels or electronic bar codes displayed on the screen of a mobile phone, tablet or computer, the best-in-class LI2208 linear imager delivers unparalleled performance, every time.The next generation in 1D scanning, the LI2208 provides the same reliability and ergonomics of our most popular scanner, the LS2208, with enhanced features that let you scan more types of bar codes at a greater distance. From the retail POS to shipping/receiving and hotel check-in, the LI2208 allows your workers to better meet the needs of your business.
Excellent 1D Scanning Performance
Delivers superior scanning speed and a wide data capture range
Captures Virtually All 1D Bar Codes on Any Surface — Including Mobile Phone Displays
Capture bar codes printed on traditional paper labels or displayed on the screen of a mobile phone, tablet or computer
Industry-Leading Working Range
Reads 13 mil 100% UPC bar codes from 1in. (2.54cm) to over 30in. (76.2cm) as well as high-density codes and extended ranges for greater application flexibility
Patented Single Circuit Board Construction
Maximizes durability and reduces downtime by removing the most common points of failure
Compatible with 123Scan² and Scanner Management Service (SMS)
Dramatically reduces management time and cost, from initial configuration to day-to-day management; SDK available for custom development
Superior Motion and Angular Tolerance
Bar codes can be captured faster, and there is no need to pause during scans
International Keyboard Support
Support for over 90 international keyboards enables easy deployment anywhere in the world
Withstands 100 Consecutive Drops to Concrete and 1,000 Consecutive 1.64ft. (0.5m) Tumbles
Ensures reliable operation despite the inevitable everyday drops to help maximize uptime
Flexible Modes — Handheld and Presentation
Gooseneck Intellistand enables presentation scanning and automatic switching between hands-free and handheld operation
| Dimensions (HxWxL) |
6.30in. x 2.64in. x 3.90in. (16cm x 6.7cm x 9.9cm) |
|---|---|
| Weight | 4.95oz (140g) |
| Voltage and Current |
5VDC ± 10% <165mA scanning <40mA standby <2.5mA USB suspend <4.0mA low power mode (when enabled, RS232 and Keyboard Wedge only) |
| Power Source | Host power or external power supply |
| Color | Twilight Black; Nova White |
| Supported host interfaces | USB, RS232, Keyboard Wedge and IBM RS485 |
| Keyboard Support | Supports over 90 international keyboards |
| Skew Tolerance | ±65 Degrees |
| Pitch Tolerance | ±65 Degrees |
| Roll Tolerance | ±45 Degrees |
| Scan Pattern | Single bright aiming line |
| Scan Angle | Horizontal 35 Degrees |
| Scan Speed | 547 scans per second |
| Motion Tolerance | 25 in. (63.5cm) per second |
| Light Source | LED Class 1 Device 617nm (amber) |
| Min. Print Contrast | 15% MRD |
Warranty & Returns
Warranty, Returns, And Additional Information
Warranty
- Limited Warranty period (parts): 3 years
- Limited Warranty period (labor): 3 years
- Read full details
Return Policies
- Contact Manufacturer for Assistance
- This item is covered by Newegg.com's Manufacturer Warranty Only Return Policy.
- Read full return policy for details.
Manufacturer Contact Info
- Manufacturer Product Page
- Manufacturer Website
- Support Phone: 1-866-289-6686
- Support Website
- View other products from Motorola
LOADING...
LOADING...
The Motorola LI2208-SR7U2100AZN is a corded handheld 1D barcode scanner with USB connectivity and 547 scans-per-second performance, suited to retail checkout, shipping, and receiving workflows that need fast scanning of printed labels or barcodes on screens.
Recommended For
- Retail checkout teams at a fixed counter that scan mainly 1D product barcodes, including codes shown on customer phone or tablet screens, and can keep the scanner connected by USB.
- Warehouse or stockroom staff working near a host computer who need to scan 1D labels at varied distances, such as during receiving, inventory counts, or checking rack labels.
- Specialty retail or light-manufacturing workers who handle small, high-density 1D barcodes on items such as electronic components and need a handheld, corded scanner at a workstation.
- Event registration, hotel check-in, or similar desk-based teams that scan 1D ticket or reservation barcodes and do not need to roam far from the connected computer.
Spec Summary
| Attribute | Value |
|---|---|
| Best For | Handheld, corded scanning of 1D barcodes, including barcodes displayed on LCD screens, with a USB connection |
| Scanning Performance | 1D linear imager scans at 547 scans per second, with a 31-inch depth of field, 15% minimum print contrast, and pitch/roll/yaw angles of ±65°/±45°/±65° |
| Connectivity | Corded USB interface |
| Scanning Features And Durability | Auto Aim for scanning accuracy; withstands 6-foot drops to concrete and has an IP42 seal against dirt and water splashes; can scan in direct sunlight |
| Physical Specifications | Handheld, black; 2.75 × 7.34 × 3.84 inches and 0.49 lb |
| Model Identifiers | Motorola LI2208-SR7U2100AZN |
| Illumination | LED light source |
