MOTOROLA SBG900 SURFboard Wireless Cable Modem Gateway 38Mbps Downstream, 30Mbps Upstream Ethernet Port IEEE 802.11, IEEE 802.11b, DSSS, 802.11g OFDM IEEE 802.3, IEEE 802.3u

OUT OF STOCK.
  • 38Mbps Downstream, 30Mbps Upstream
  • Ethernet Port
  • IEEE 802.11, IEEE 802.11b, DSSS, 802.11g OFDM IEEE 802.3, IEEE 802.3u
Specs
Reviews

Learn more about the Motorola SBG900

Model
Brand MOTOROLA
Model SBG900
Details
Type Cable Modem
Interface Ethernet Port
Standards IEEE 802.11, IEEE 802.11b, DSSS, 802.11g OFDM
IEEE 802.3, IEEE 802.3u
Max Transmission Rate 38Mbps Downstream, 30Mbps Upstream
Features
Features Device Type: Cable modem and wireless network access point
RF Frequency Range: 11 channels with center frequencies for 2.412 to 2.462 GHz
Transmit Power: +17 dBm (EIRP)
Protocols Supported: RIPv2
Uplink Ports: 1
Cable Interface: F-Connector, female
CPE Network Interface: USB, Ethernet 10/100Base-T (auto-sensing)
Data Protocol: TCP/IP
Modem Downstream Modulation: 64 or 256 QAM
Downstream Maximum Data Rate: 38 Mbps
Downstream Bandwidth: 6 MHz
Downstream Frequency Range: 88 to 860 MHz
Modem Upstream Modulation: 8, 16, 32, 64, 128 QAM or QPSK
Upstream Maximum Data Rate: 30 Mbps
Upstream Bandwidth: 200 kHz, 400 kHz, 800 kHz, 1.6 MHz, 3.2 MHz, 6.4 MHz
Upstream Frequency Range: 5 to 42 MHz (edge to edge)
Mechanical Antennas: 1 external (non-removable), 1 internal
LED Indicators: Power, Send, PC Activity, Receive, Online, Wireless
Input Voltage Range: 100 to 240 VAC, 50 to 60 Hz
Power Consumption: 9 Watts

PCs can be located where it is most convenient, not where there is a physical connection
Surf the Internet at speeds up to 100 times faster than a 28.8k analog modem
Offers 802.11g wireless technology with a range of up to 328 ft indoors and 1312 ft outdoors
Everyone on your network (up to 252 users) can share a single broadband connection
64-bit and 128-bit WEP security keeps hackers and viruses from attacking your network
Additional Information
Date First Available August 17, 2007

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year
