Question 1

EVGA 02G-P4-3757-KR G-SYNC Support GeForce GTX 750 Ti 2GB 128-Bit GDDR5 PCI Express 3.0 FTW w/ ACX Cooling Video Card. Will this video card be compatibly with this motherboard ?

Accepted Answer

Absolutely. That card will work in any motherboard with a PCI-expresss x16 expansion slot. Doesn't even matter if the slot is PCI-express 2.0 or 3.0.

Question 2

Does it support Windows 10?

Accepted Answer

Yes, I own this board and updated to Windows 10 last year - everything went smoothly; didn't even have to install a BIOS update.

Question 3

will this run Windows 10???

Accepted Answer

Yes, I just upgraded to windows 10 recently and have had no problems at all!

Question 4

will I be able to overclock my g3258?

Accepted Answer

Yes, this dual core CPU is one of the most over clockable Intel CPU's
It has a " K " suffix and can be taken from the stock 3.2 Ghz to
4 Ghz and possibly more.

Question 5

would this be compatible with a Intel Core i5-3570K, and also does the motherboard support overclocking ?

thanks :)

Accepted Answer

Unfortunately this board will only support the Haswell line of processors. The board is a 1150 socket and the i5-3570K uses the 1155 socket. Also, yes this board supports overclocking.

Question 6

Should I install my PCI-ex 2.0 graphics card in the PCI-ex 3.0 slot or the PCI-ex 2.0 slot? Thanks!

Accepted Answer

To my knowledge (please correct me, someone, if I'm wrong), you can install PCI-ex 2.0 cards into PCI-ex 3.0 slots. The different versions of the slots just increases the bandwidth (i.e. version 3 has a higher maximum bandwidth than version 2). It shouldn't matter which slot you install the card in, as most cards do not utilize the maximum bandwidth for version 2, let alone version 3.

In short, it really doesn't matter which slot you put it in.

Cheers!

Question 7

Is this motherboard compatible with the Coolermaster Elite 120 case? I know it's compatible with the Coolermaster Elite 110 but I wanted the 120 for the Optical Disc Drive option. Any replies are much appreciated :)

Accepted Answer

I installed this MB in SILVERSTONE Black Aluminum / Steel ML04B Micro ATX Media Center / HTPC Case, not the one you chose. However, I have built many computers and do not hesitate to install any mATX motherboard in a case that is built for mATX or ATX. There is nothing about this MB that deviates from the mATX standard. So if the case you chose will do mATX or ATX then you're good to go.

Question 8

I see that this has the TPM connector, but I wanted to make sure. Does this motherboard meet all the requirements to enable hardware encryption (eDrive)? I can't seem to see if it supports UEFI 2.3.1. I have a self encrypting Samsung SSD and I want to make sure BitLocker will use the hardware encryption rather than software. Thank you for the help.

Accepted Answer

It is EUFI but I don't know the version. I didn't use it long enough to get that deep. I swapped it out for a MSI Gaming 5. In fact it is sitting in my parts closet with 8 gigs of memory, a i5 3.5 processor and a third party fan seeking a buyer. I went with the Gaming 5 because of the internal SSD connection on board. So it is waiting for a SAMSUNG 950 PRO M.2 256GB to be installed as the boot drive. However when I was using it the newest games I played using it were the two newest Wolfenstien releases. I tried the new Tomb Raider with it but my GTX 750 just couldn't keep up so I bought a GTX 960 which changed everything.

Question 9

If I use a PCI-e 1.0 slot will it slow down the PCI-e 3.0 slot?

Accepted Answer

The motherboard manual says nothing about the PCI-e 3.0 x16 slot being affected when a PCIe x1 slots is occupied.

The motherboard's notes indicate that if the PCI-e 3.0 x16 and PCIe 2.0 x16 slots are both occupied, speed is affected. In that case they can either both be operated in x4 mode or be linked via Crossfire.

Question 10

If use a PCI-e 1 slot will it slow down the 3.0 slot?

Accepted Answer

They are all 3.0 slots, so perhaps you mean if you use an x1 slot will it slow down the x16 slot? It just isn't a concern. That's what they're there for. That being said, you probably would not install an x1 card in an x16 slot. It would work just fine, but you would reserve an x16 slot for x4, x8 or x16 cards.
