Question 1

Will this work with Ryzen 5000 sees?

Accepted Answer

No. Risen 5000 CPUs use the AM4 socket. This motherboard has an AM5 socket, so it is incompatible with AM4 socket CPUs.

Question 2

If I were to place a  newest gen PCI 5.0 NVME SSD in the M.2_1 5.0 slot, will it cause the PCI_E1 Gen PCIe 5.0 slot to run at x8, rather than the full x16 for my current 4th gen/future 5th Gen GPUs?

Accepted Answer

Yes I believe so, but you should check the manual for the MB by checking MSI's website.

Question 3

Manufacturer only has 5200mhz memory on QVL list. If I get this board, can you recommend the highest speed memories that will work?

Accepted Answer

I'm not sure about the highest speed that will work but I'm using a kit of 6000 CL30 and it's working great!

Question 4

Does this motherboard have overclocking and tweaking features?

Accepted Answer

Yes, this motherboard supports overclocking features, including memory overclocking profiles and optimized power delivery for enhanced performance.

Question 5

Can I place a 4.0 gpu in the 5.0 slot?

Accepted Answer

Yes, you can place a PCIe 4.0 GPU in the PCIe 5.0 slot. The PCIe slots are backward compatible, so a 4.0 GPU will work in a 5.0 slot.

Question 6

How many M.2 Slots does this motherboard have?

Accepted Answer

4 x M.2
M.2_1 Source (From CPU) supports up to PCIe 5.0 x4, supports 22110/2280 devices
M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices
M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices

*PCI_E4 & M2_4 share the bandwidth. M2_4 will run at x2 speed when installing device in the PCI_E4 slot.

Question 7

Does this board support 5.1 surround over spdif / toslink in Windows 11?

Accepted Answer

Yes, this board supports 5.1 surround sound over S/PDIF-Out in Windows 11.

Question 8

Will this carry 5.1 surround sound over s/pdif to a receiver?

Accepted Answer

Yes, the motherboard has an S/PDIF-Out port which can carry 5.1 surround sound to a receiver.

Question 9

I know this is a WIFI motherboard, but would it be possible to take out the pre-installed antennas in order to put a WIFI card? And if so, would the WIFI card go in the same spot or does it have a different slot that the motherboard already has?

Accepted Answer

The antenna are screwed into two posts already soldered into the IO port of the motherboard, but you can disable the integrated Wi-Fi, Blue-tooth, or both if you want. You can connect the provided antenna on these posts, or if you prefer a wall mounted antenna, you can purchase one separately and connect it to these posts. There is nothing stopping you from adding additional hardware in the other slots unless you get a new 3 fan 4080 GPU as I recently discovered takes up 3 slots plus space for the support bracket.
