Designed with key features for the graphics and photography professional, NEC MultiSync PA Series displays are smart investments for your desktop. These models include the SpectraViewII Color Calibration Solution, which combines award-winning NEC LCD display technology with a color measurement sensor and sophisticated software. The result is a highly accurate, reliable, repeatable and feature-rich display calibration and profiling solution.
Color and brightness uniformity were paramount in the design of these high-performance displays, making them ideal for graphic arts, desktop publishing, photography and other color-critical environments. In addition to accurate color, the displays also feature Picture-in-Picture and Picture-by-Picture modes for a real-time preview of work in a second color space.
Designed with key features for the graphics and photography professional, NEC MultiSync PA Series displays are smart investments for your desktop. These models include the SpectraViewII Color Calibration Solution, which combines award-winning NEC LCD display technology with a color measurement sensor and sophisticated software. The result is a highly accurate, reliable, repeatable and feature-rich display calibration and profiling solution.
Color and brightness uniformity were paramount in the design of these high-performance displays, making them ideal for graphic arts, desktop publishing, photography and other color-critical environments. In addition to accurate color, the displays also feature Picture-in-Picture and Picture-by-Picture modes for a real-time preview of work in a second color space.
Superior Screen PerformanceBest-in-class 10-bit active matrix IPS panel with 98.1% coverage of AdobeRGB color space and 178º horizontal and vertical viewing angle provides optimum performance for displaying color images. Color Vision Emulation allows a real-time preview of Type P/D/T color vision deficiencies in support of Color Universal Design.
14-bit LUTsInternal 14-bit programmable 3D lookup tables (LUTs) allow the display of 1.07 billion colors out of a palette of 4.3 trillion for lossless color and smooth images and hardware calibration.
AmbiBrightAmbiBright ambient light sensor automatically adjusts the backlight depending on the brightness of ambient lighting conditions. It also tells the monitor to enter power saving mode whenever the ambient lighting falls below a predetermined value (like when lights are shut off at the end of the day), which can significantly reduce energy consumption.
Ambix3 & DisplayPort, USB HubAmbix3 allows up to four inputs (VGA, DVI-I and DVI-D) to be connected to a single monitor and for each of the three signals to be displayed with the press of a button. Built-in USB hub with DisplaySync Pro controls two computers with only one keyboard and mouse.
Height-adjust, Pivot, Tilt and Swivel CapabilitiesThe NEC MultiSync PA241W-BK-SV features a 4-way ergonomic stand with capabilities of pivot between landscape to portrait orientations, height-adjustment (up to 150mm), tilt and swivel, allowing you to create an ideal ergonomic display orientation for maximum viewing comfort.
SpectraViewIISpectraViewII Color Calibration Solution, which includes software and colorimeter, helps the display achieve accurate, consistent and repeatable color performance.
Learn more about the NEC Display Solutions PA241W-BK-SV
Model
Brand
NEC Display Solutions
Model
PA241W-BK-SV
Cabinet Color
Black
Display
Screen Size
24.1"
LED Backlight
No
Widescreen
Yes
Resolution
1920 x 1200
Viewing Angle
178° (H) / 178° (V)
Monitor Pixel Density
0.27mm
Display Colors
1.07 Billion
Brightness
360 cd/m2
Contrast Ratio
1,000:1
Response Time
16ms, 8ms(GTG)
Panel
IPS
Display Type
WUXGA
Horizontal Refresh Rate
31.5 - 93.8/118.4 KHz
Vertical Refresh Rate
51 - 85 Hz
Connectivity
Input Video Compatibility
Analog RGB, Digital
Connectors
D-Sub, DVI-D, DisplayPort, USB
D-Sub
1
DVI
2
HDMI
No
DisplayPort
1
USB 2.0
2 up / 3 down
Power
Complies with
VESA DPMS power management
Power Consumption
95W typ w/o USB, 114W max with USB Power Savings Mode: 1W (without USB active)
Convenience
Regulatory Approvals
UL / C-UL, CE, Gost/PCT, PSB, CCC, NOM, IRAM, TUV GS, FCC Class B/Canadian DOC, C-tick, MPR II / MPR III, VCCI (class 2), JIS C 61000-3-2, static electricity guideline, low emission guideline, TUV-Ergonomie, ISO9241-307, TCO '99, US Mercury regulations, WEEE, RoHs, GEEA
Stand Adjustments
Height, Pivot, Swivel, Tilt
Built-in TV Tuner
No
Built-in Speakers
No
HDCP Support
Yes
Features
Features
SpectraViewII Color Calibration Solution, which includes software and colorimeter, helps the display achieve accurate, consistent and repeatable color performance
98.1% coverage of AdobeRGB color space
Superior screen performance (1000:1 contrast ratio, 1920 x 1200 native resolution, 360cd/m2 brightness)
Supports internal programmable 14-bit 3D lookup tables (LUTs) for calibration
DisplaySync Pro controls two computers with only one keyboard and mouse
Color Vision Emulation for type P/D/T supporting Color Universal Design
AmbiBright ambient light sensor automatically adjusts the display's brightness based on lighting conditions
Wide connectivity includes DisplayPort, two DVI-D inputs and USB hub
100 x 100mm, 200 x 100mm VESA Hole Configuration
Dimensions & Weight
Dimensions (H x W x D)
Net (with stand): 21.9 x 14.9-20.8 x 9 in Net (without stand): 21.9 x 14.3 x 3.3 in
Weight
Net (with stand): 23.4 lbs. Net (without stand): 16.3 lbs.
Environmental
Temperature Range
5 - 35 Degrees C / 41 - 95 Degrees F
Humidity Range
30 - 80%
Additional Information
Date First Available
September 14, 2010
