Intel Wireless-AC 9260 802.11ac Bluetooth 5.0 M.2 WiFi/Bluetooth Adapter 9260NGW
- Intel recommended wireless solution for 8th Generation Intel Core processors (older PC or other processors may not work)
- M.2 2230 Form Factor - M.2 2230 modules enable system configuration and platform usages flexibility with the use of a standard Key A or E socket for attaching the module.
- Connector interface : NGFF(M.2) Interface (DO NOT USE FOR HALF MINI PCI-E) , Speeds(Max): 1.73Gbps
- Compatibility: Only compatible with Intel-based, Linux or Windows 10/11 64-bit machines, which do not current utilize a 9560 CNVI part. PC must have available M2 slot with Key A or Key E
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
No vPro Technology
Intel recommended wireless solution for 8th Generation Intel Core processors (older PC or other processors may not work)
Microsoft Windows 10* Ready (64-bit only)
M.2 2230 Form Factor - M.2 2230 modules, Key A or Key E
Intel Wireless-AC 9260 is the first Intel Wi-Fi module that provides Gigabit Wi-Fi speeds. When using 160MHz channels, it can deliver up to 1.73Gbps maximum theoretical throughput, nearly 12x faster than baseline 1x1 BGN (150Mbps) Wi-Fi used in today's PCs.
Bluetooth 5 provides 4x the range over Bluetooth? 4.2 Low Energy with the same power, doubles the transmit speed and improves the broadcasting functionality. This translates to better coverage, improved location-based services and simpler connectivity between devices.
Optimized for Intel Platforms
Downlink MU-MIMO allows an access point to simultaneously transmit data to multiple clients and can improve overall downlink network capacity by up to 3x.
Product Type: KEY_TAB KEY_TAB Wi-Fi/Bluetooth Combo Adapter
Technical Information
Wireless LAN Standard: KEY_TAB KEY_TAB IEEE 802.11ac
Bluetooth Standard: KEY_TAB KEY_TAB Bluetooth 5.0
ISM Band: KEY_TAB KEY_TAB Yes
UNII Band: KEY_TAB KEY_TAB Yes
ISM Maximum Frequency: KEY_TAB KEY_TAB 2.40 GHz
UNII Maximum Frequency: KEY_TAB KEY_TAB 5 GHz
Wireless Transmission Speed: KEY_TAB KEY_TAB 1.73 Gbit/s
Interfaces/Ports
Host Interface: KEY_TAB KEY_TAB M.2
Physical Characteristics
Form Factor: KEY_TAB KEY_TAB Internal
Height: KEY_TAB KEY_TAB 0.9"
Width: KEY_TAB KEY_TAB 1.2"
Depth: KEY_TAB KEY_TAB 0.1"
Weight (Approximate): KEY_TAB KEY_TAB 0.10 oz
