Compatible with M4300-96X models (XSM4396K0, XSM4396K1). The NETGEAR M4300-96X is a 2RU modular switch that comes either empty or pre-populated with 48 SFP+ ports and supporting up to 96-port 10GBASE-T copper (RJ-45) with first 48 ports capable of PoE+, 96-port 10GBASE-X fiber (SFP+), 24-port 40GBASE-X fiber (QSFP+), or a combination. The M4300 family provides world-class services for server and storage interconnect, mid-enterprise edge and SMB core. SDVoE-Ready, M4300 switches streamline AV-over-IP deployments with Zero Touch multicast. Layer 3 feature set includes static, policy-based and dynamic routing as standard. M4300-96X is backed by NETGEAR ProSAFE Lifetime Limited Warranty and 24/7 support including lifetime chat.

Model
Brand	NETGEAR
Model	APS600W

Details
Type	Power Supply
Specifications	Safety IEC 60950-1, EN 60950-1, CB Certificate/Report, UL/CSA 60950-1 EMC CC / ICES-003 Emission (USA/Canada) CRISP 22 Emission (International) EN61000-4-2 Electrostatic Discharge EN61000-4-3 Radiated RFI Immunity EN61000-4-4 Electrical Fast Transients level 4 EN61000-4-5 Electrical Surge Level EN61000-4-6 RF Conducted EN61000-4-8 Power Frequency Magnetic Fields EN61000-4-11 Voltage Dips and Interruptions EN61000-4-8 Power Frequency Magnetic Fields EN61000-4-11 Voltage Dips and Interruptions

Features
Features	Used in Switch Model M4300-96X M4300-16X AC input 90–132VAC, 8A, 47–63 Hz or 180–264VAC, 4A, 47–63 Hz DC output +54.5 VDC, 11A Dimensions(HxWxD) 1.6 x 2.9 x 7.3 in. (40 x 73 x 185 mm) Operating temperature 23 to 122ºF (–5 to 50ºC) Operating relative humidity 5% to 95% noncondensing Operating altitude level Up to 16,000 feet (5,000 m) above sea level Storage temperature –40 to 185ºF (–40 to 85ºC ) Storage altitude level Below 49,000 feet (15,000 m) above sea level MTBF 4,534,733 hrs (~517 years) @ 77ºF (25ºC)

Additional Information
First Listed on Newegg	January 28, 2020
