OBi1000 Series IP Phones

High Fidelity Voice Quality, Cloud-Management and Premium Functionality at an Affordable Price

OVERVIEW

OBi1000 Series Business-Class Color IP Phones

With Support for Up to 24* Lines and Up to Six SIP, Google Voice™ and One OBiTALK VoIP Services

High-Definition ‘HD’ Voice for Crystal-Clear Calls

OBi 1000 Series IP phones are designed from the outset to support High Definition (HD) voice calling. From the device’s physical acoustics through to the digital conversion of audio, Obihai’s engineers have fine-tuned every element to ensure a crystal clear calling experience.

OBi Phones and OBiTALK Cloud Management

OBi 1000 Series IP phones are managed remotely via the OBiTALK cloud-management portal using any mainstream browser, enabling fast and easy deployment and maintenance. The always-on remote management and diagnostic capabilities enable IT and support staff to manage and troubleshoot devices regardless of location and even deploy new devices without the requirement for a site visit. Additionally, OBiTALK can help keep device firmware up-to-date with new features as they are released, further enhancing the user’s experience and the enterprise’s investment.

Functionality That’s Easy to Use

Commonly used call functions such as putting a caller on hold, transferring, picking-up or conferencing calls are intuitive to use and set-up. Other calling and user features are easily programmed into either the line keys next to the display – in total, there are up to 24* – or the eight (8) programmable keys within easy reach on the right side of the phone body. This allows for a customizable user experience based on the intended use of the device. The OBi 1000 Series IP phones are adaptable to the user and their job role, though creating a more efficient call management platform for the business and conveying a more professional image to its customers.

OBi IP Phone Features	OBi1022 Leader	OBi1032 Manager
VoIP Services	6	6
Line / Call Appearances Keys	5	3
Physical Keys (All Programmable)	10	11
Lines / Call Appearances	10	12
Total Available Line Keys – Page Tabs -	10 - 2	12 - 4
Programmable Feature Keys	1	8
Total Programmable Keys	11	19
Side Car Support	-	Yes - 2
Keys per Side Car	-	16
USB 2.0 Ports	1	2
USB Storage Media	Yes	Yes
OBi WiFi	Yes	Yes
OBiBT (Headset or Mobile Phone Pairing)	Yes	Yes
Headset Support	Yes	Yes
RJ9 Jack	No	Yes (EHS)
3.5 mm Jack	Yes	Yes
Bluetooth	Yes with OBiBT	Yes with OBiBT
WiFi (802.11n)	Yes with OBiWiFi	Yes with OBiWiFi
Ethernet Ports (RJ45) and Type	2 10/100 Fast Ethernet	2 10/100 Fast Ethernet
Power Over Ethernet (802.3 af)	Yes	Yes

Features of the OBi1000 Series Business IP Phones:

Large Vivid Color Display – User Configured Themes and Multi-Dimensional Navigation with Top-Anchored Time and Date
Remotely Customizable via XML Download – User Interface Labelling, Key/Button Functionality, Applications
Up to 24 Lines or Call Appearances* – Programmable Across Six (6) VoIP Services (SIP and Google Voice) + OBiTALK
Universal Interoperability with SIP and VoLTE Call Control Platforms
Secure Remote Provisioning and Management Versatility via SP’s In-House System and/or OBiTALK Cloud-Management
Zero-Touch Customization and Service Activation APIs to Minimize Deployment Costs / Complexity
High Definition Speech Technology for Crystal-Clear Conversations - VoIP Codecs Supported: G.722, G.711, G.726, G.729, iLBC, OPUS8
Full-Duplex Speakerphone with Built-In Class D Amplifier and Audio Equalizer
Headset Support via RJ9, 3.5mm Jacks (EHS Support) or Bluetooth
Dual Ethernet with Power over Ethernet (PoE): Gigabit Ethernet (OBi1062) or Fast Ethernet (OBi1032)
Integrated WiFi Connectivity – Built-in or Via OBiWiFi USB Adapter
16-Key Side Car Option – Up to Two Side Cars per Phone
Built-In Five Party Conference Bridge
Personal Contact Phone Book with Import/Export/Sync Functions, Call History, Picture Caller ID
Obihai Call Routing and Bridging Technology
Global Deployment: Language Localization and Country-Specific Dialing, Ringing, In-Call Tones

Developed, Designed and Supported by Obihai Technology

The OBi1000 Series IP phone electronics and acoustics are designed, developed and supported in-house, by Obihai engineers in California. This includes the SIP software stack used on devices to ensure a reliable experience with all major voice platforms and service provider deployments. The OBi1000 Series IP phones are built with a high-performance system-on-a-chip platform to ensure high quality voice conversations. OBi1000 Series IP phones support high-availability and reliability with in-service, unobtrusive management and software upgrade support.

Comprehensive Support for Major IP Voice Platforms and Services – SIP and VoLTE

In addition to support for most industry-standard SIP-based voice services, the OBi IP Phone adds support for Google Voice™ as well as device-to-device calling using the OBiTALK voice protocol – all configured and managed by the network/service administrator/owner. The OBi 1000 Series IP phones also work with major VoIP softswitch platforms such as Asterisk, BroadSoft, Metaswitch, FreeSwitch and Kamailio.

Robust Telephony Features:

Multi-Line / Multiple Calls
Shared Call / Bridged Line Appearance
Busy Lamp Field (BLF) – Regular, Pick-up and Speed Dial
On-Hook Dialing
Caller ID – Name & Number, Photo
Call Waiting, Call Queued
Multiple Distinctive Ringtones Based on Who is Calling
Auto Answer Intercom Call, Page Call
Page Groups (2)
Call Hold
Music on Hold
Call Swap
Call Park and Call Un-park
Call Pick-Up – Selective and Group
Message Waiting Indication - Visual and Tone Based
Speed Dialing by code of 99 OBi Endpoints, Buddies or Numbers (E.164 or URI)
Call Logs (200) – Dialing from Call Logs
Personal Phone Book – Each Entry with Multiple Numbers, Photo, Grouping
Hot Line and Warm Line Calling
Five-Way Conference Calling with Local Mixing
Call Forward - Unconditional
Call Forward on Busy
Call Forward on No Answer
Call Transfer -- Blind or Attended
Anonymous Call
Block Anonymous Call
Do Not Disturb – Do Not Ring
Call Return – Call Back on Busy
Repeat Dialing
Immediate Divert
Multiple Ringtones – Upload Custom Ringtones
Screen Saver – Upload Screen Saver with Slideshow Image(s)
Secure Encrypted Voice Communication Support
Independent Mic and Speaker Volume Adjustment: Speaker, Handset, RJ9 Headset, 3.5mm Headset, Bluetooth Headset
Administrator Password Protected Factory Reset
Zero-Touch Customization – Factory Defaults Defined by Service Provider
OBiTALK Cloud Management / Troubleshooting
Syslog Event Logging
