Obihai OBI110 VoIP Telephone Adapter with Google Voice, SIP & Phone Line Gateway

OPEN BOX Product Type
OUT OF STOCK.
  • Google Voice Officially Supported Device
  • Easy to Set-Up Using OBiTALK.com
  • Free Domestic and Super Low-Cost International Calling
  • Works with Up to Two (2) VoIP Services
The Open Box Product Disclaimer applies to this product.
Specs

Learn more about the Obihai Technology, Inc. OBI110

Model
Brand Obihai
Model OBI110
Type
Type Accessories
Spec
Security Local Access Interface: IVR Password
Remote Access Interface: User Name & Password Access via HTTP, TFTP - HTTPS
Device Web Page Standard: HTTP v1.1, XMLv1.0
Secure Remote Provisioning: TFTP, HTTP, HTTPS
Ports Internet (WAN): 1 x 10/100BaseT Ethernet Port (802.3)
Phone (FXS): 1 x RJ-11 FXS Analog Phone Port
Line (FXO): 1 x RJ-11 FXO Analog Line Port
LEDs Power On, Device Status, Upgrade in Progress Status, Packet RX/TX, Phone Port Status (Enabled, In-Use), Line Port Status(Enabled, In-Use)
Power Input Power: AC Input: 100 to 240 Volts 0.3A 50-60Hz (26-34 VA) Output Power: DC: +12V 1.0 Amp Max
Dimensions 4.5" x 4.2" x 1.2"
Weight 9 ounces
Temperature 0 degree C to 45 degree C
Humidity 10% to 90%, Non-Condensing
Specifications Voice Service Bridge and Telephone Adapter with SIP, OBiTALK, Telephone & Phone Line Interfaces

Mounting: Desktop or Wall Mountable

Microprocessor:
Chip Vendor:Obihai SoC
Width of Machine Word: 32 bit
Instruction Set: MIPS

FXS SLIC (Subscriber Line Integrated Circuit) & FXO Subsystem:

Ringer Specifications:
Ring Frequency: 14Hz - 68Hz
Ring Waveform: Trapezoidal, Sinusoidal
Ring Voltage: 55v - 85v

Maximum Ring Load: 5 REN (Ringer Equivalence Number)

FXS (PHONE Port) Configuration Settings:
Recursive Digit Map & Associated Outbound Call Routing
On-Hook Tip Ring Voltage: 30v - 52v
Off-Hook Current Max: 15mA - 45mA
Impedance: 12 Independent Settings
DTMF Playback Level: -90 dBm - 3dBm
Caller ID Method (FSK Bell202, FSK V.23, DTMF FI/SE/DK)
Caller ID Trigger (Before / After First Ring, Polarity Reversal)
Channel Tx Gain: -12dB - 12dB
Channel Rx Gain: -12dB - 12dB
Silence Detect Sensitivity
HookFlash Time Max
HookFlash Time Min
CPC Delay Time
CPC Duration
Idle Polarity
Connect Polarity

FXO (LINE Port)Configuration Settings:
Recursive Digit Map & Associated Inbound Call Routing
Ring Delay
Detect CPC
CPC Time Threshold
Detect Polarity Reversal
Detect Far End Long Silence
Detect Near End Long Silence
Silence Detect Sensitivity
Silence Time Threshold
Detect Disconnect Tone
Disconnect Tone Pattern - Programmable
AC Impedance: 16 Settings
On-Hook Speed: 0.5ms, 3ms (ETSI), 26 (AU)
Tip-Ring Voltage: 3.1v, 3.2v, 3.35v, 3.5v
Min Operational Loop Current: 10mA, 12mA, 14mA, 16mA
Current Limiting Enable
Channel Tx Gain
Channel Rx Gain
Line In-Use Voltage Threshold
Line In-Use Current Threshold
Caller ID Detect Method: FSK (Bell 202), FSK (V.23), DTMF (FI, SE, DK)
DTMF Playback Level

Logical FXS to FXO Relay: For Service Continuity in Case of VoIP Service Failure

*More information, Please see obihai website.
Features
Features Robust Telephony Features:
Message Waiting Indication - Visual and Tone Based
Speed Dialing of 99 OBi Endpoints or Numbers
Three Way Conference Calling with Local Mixing
Hook Flash Event Signaling
Caller ID - Name & Number
Caller ID Spoofing
Call Waiting
Call Forward - Unconditional
Call Forward on Busy
Call Forward on No Answer
Call Transfer
Anonymous Call
Block Anonymous Call
Do Not Disturb
Call Return
Repeat Dialing

Powerful Call Routing & Voice Service Features:
SIP Support for Voice and Fax Over IP from Internet Telephony Service Providers
OBiTALK Managed VoIP Network for OBi Endpoint Devices & Applications
High Quality Voice Encoding Using G.711, G.726, G.729 Algorithms
Recursive Digit Maps & Associated Call Routing (Outbound, Inbound)
Service Continuity in Case of Network Failure (Configurable)
Additional Information
Date First Available April 06, 2012
