BLX120 Brushless 4S ESC, ARA390264
- ARRMA BLX120 Brushless 4S ESC, ARA390264
- BLX120 Brushless 4S ESC
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
The BLX120 120A waterproof ESC provides consistent power control and is 4S LiPo ready.
Features: Fitted with super-reliable EC5 connectors and sporting a built-in cooling fan for reduced heat during intense driving action, the BLX120 ESC has over voltage protection, and a two-stage LiPo cut off for added cell management. The fitted 12AWG high-quality wires and 6V BEC unit are combined with a three mode throttle profile (FWD/REVERSE/BRAKE) to provide the ultimate driving experience. SPECIFICATION Battery usage 3S LiPo ( 11.1V ) or 4S LiPo ( 14.8V ) Low Voltage Cut-Off (LVC) 3.4V per cell Thermal Protection Temperature 125°C / 257°F Over-Voltage Protection Over 17.2V BEC Voltage 6V BEC Current 3A ESC Length 43mm / 1.69" ESC Height 34mm / 1.34" ESC Width 54.5 mm / 2.15" (Including hold-down tabs) ESC Weight 150g / 5.3 oz Receiver Wire Length 170mm / 6.70" Battery Wire Length 225mm / 8.86" Motor Wire Length (Including Connector) 200mm / 7.87" Switch Length 21mm / 0.83" Switch Width 13.3 mm / 0.52" Switch Height 16mm / 0.63" Motor Bullet Connector Size 4mm / 0.16" Wire
Connector Type 2xEC5 Includes: 1 x BLX120 Brushless 4S ESC 1 x Loop Connector
Features: Fitted with super-reliable EC5 connectors and sporting a built-in cooling fan for reduced heat during intense driving action, the BLX120 ESC has over voltage protection, and a two-stage LiPo cut off for added cell management. The fitted 12AWG high-quality wires and 6V BEC unit are combined with a three mode throttle profile (FWD/REVERSE/BRAKE) to provide the ultimate driving experience. SPECIFICATION Battery usage 3S LiPo ( 11.1V ) or 4S LiPo ( 14.8V ) Low Voltage Cut-Off (LVC) 3.4V per cell Thermal Protection Temperature 125°C / 257°F Over-Voltage Protection Over 17.2V BEC Voltage 6V BEC Current 3A ESC Length 43mm / 1.69" ESC Height 34mm / 1.34" ESC Width 54.5 mm / 2.15" (Including hold-down tabs) ESC Weight 150g / 5.3 oz Receiver Wire Length 170mm / 6.70" Battery Wire Length 225mm / 8.86" Motor Wire Length (Including Connector) 200mm / 7.87" Switch Length 21mm / 0.83" Switch Width 13.3 mm / 0.52" Switch Height 16mm / 0.63" Motor Bullet Connector Size 4mm / 0.16" Wire
Specifications
12AWG ESC BatteryConnector Type 2xEC5 Includes: 1 x BLX120 Brushless 4S ESC 1 x Loop Connector
