Blue Sea 7136 187 - Series Thermal Circuit Breaker - 30Amp
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
187 - Series Thermal Circuit Breakers - Surface Mount30
Amp Circuit BreakerPN:
7136Features: Combines switching and circuit protection into a single deviceAll components meet SAE J1171 external ignition protection requirementsClear single lever operation"Trip Free" design cannot be held "ON" during fault current conditionWaterproofRecessed mounting holes for clean appearanceLarge clearance around terminal studs accept heavy gauge wire lugsRobust 5/16 terminals provide high torque connectionsLarge lever with vertical/horizontal orientation provides indication of trip statusIgnition protected - safe for installation aboard gasoline powered boatsSpecifications
Circuit Breaker Class: Type III - Switchable / Manual Reset -
Trip FreeType: Thermally
Responsive Bi-Metal BladeCase Material: Thermoset
PolyesterVoltage Rating: 48
Volts DC MaximumInterrupt Rating: 5000 Amperes @12 Volts DC 3000 Amperes @24 Volts DC 1500 Amperes @42
Volts DCOperating Temperature Range: -25C° to +82C°
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer birth defects or other reproductive harm. For more information go to P65Warnings. ca. gov.
Product: BLUE SEA 7136 CIRCUIT BREAKER 30A
Manufacturer: Blue Sea Systems
Manufacturer Part No: 7136
Product: BLUE SEA 7136 CIRCUIT BREAKER 30A
Amp Circuit BreakerPN:
7136Features: Combines switching and circuit protection into a single deviceAll components meet SAE J1171 external ignition protection requirementsClear single lever operation"Trip Free" design cannot be held "ON" during fault current conditionWaterproofRecessed mounting holes for clean appearanceLarge clearance around terminal studs accept heavy gauge wire lugsRobust 5/16 terminals provide high torque connectionsLarge lever with vertical/horizontal orientation provides indication of trip statusIgnition protected - safe for installation aboard gasoline powered boatsSpecifications
Circuit Breaker Class: Type III - Switchable / Manual Reset -
Trip FreeType: Thermally
Responsive Bi-Metal BladeCase Material: Thermoset
PolyesterVoltage Rating: 48
Volts DC MaximumInterrupt Rating: 5000 Amperes @12 Volts DC 3000 Amperes @24 Volts DC 1500 Amperes @42
Volts DCOperating Temperature Range: -25C° to +82C°
WARNING: This product can expose you to chemicals including di(2-ethylhexyl)phthalate (dehp) which is known to the State of California to cause cancer birth defects or other reproductive harm. For more information go to P65Warnings. ca. gov.
Product: BLUE SEA 7136 CIRCUIT BREAKER 30A
Manufacturer: Blue Sea Systems
Manufacturer Part No: 7136
Product: BLUE SEA 7136 CIRCUIT BREAKER 30A
