Question 1

The dimensions listed for this switch indicate 8.7 inches tall.  Is this correct? My standard wall plates are all 4.5 inches tall.

Accepted Answer

I don't know where you got the 8.7" dimension.  Newegg's website has the dimensions as: 2.5 x 1.7 x 2.0.  It fits in a standard wall plate which is 4.5" high.

Question 2

will this work with a 3-pole switch?  thanks kj

Accepted Answer

No. This module replaces a single-pole-single-throw (SPST) mechanical switch.  You need the model number: RPLS540A, or RPLS541A for a three-way switch. However it is not recommended to power fluorescent bulbs with the 3-way model only incandescent or halogen). You can review the different honeywell module offerings at www-dot-yourhome-dot-honeywell-dot-com and type in the above model numbers in the honeywell web page to get more details--the manufacturer may now provide a 3-way that safely powers fluorescent bulbs.

Question 3

Will switch work with LED lights also?

Accepted Answer

Yes, I have been using this switch with the Cree 60w equivalent LED light bulbs for the last 7 months.

Question 4

The description for this timer says that the "programming is protected during power outages", which I assume to mean that it won't forget its programming whenever the power goes out. But what about the date and time; if the power goes out, will the date and time on the timer have to be reset?

Accepted Answer

Date,time, and programs are all saved for several hours after power failure.  There is an internal battery that stores all the information, so long as power comes back on before the battery is drained you won't need to worry about anything.

Question 5

I want my ordered unit to be white.

I find no way to define color.

What color(s) are you shipping?

Accepted Answer

The units I received were white.  I am not even sure if they offer this switch in any other color than white.

Question 6

Is this unit rated 15 amps or 20 amps?

Accepted Answer

1800 W (15 A @ 120 V) Lights and resistive loads (except tungsten).
1440 W (12 A @ 120 V) Tungsten lights.
Motors - 3/4 HP.

Question 7

Does it work with LED lights?

Accepted Answer

Yes, it works with LED lights. We have two switches controlling several exterior lights and they work great.
