Coating Thickness Gauge, 0 to 5000 µm
- Features an internal sensor with v-groove interface for reliable measurement on curved surfaces such as axles
- Comes with a set of calibration standards
- Allows for automatic or manual shut off
- Measurement range: 0 ... 5000 µm, 0 ... 200 mils (selectable)
- Measurement values: 0.0 µm ... 999 µm / 0 mils ... 40 mils, 1.00 mm ... 5.00 mm / 0.04 in x 0.20 in
- Measuring on: Only non-ferrous metals
- Resolution: 0.1 µm (0.0 µm ... 99.9 µm), 1 µm (100 µm ... 999 µm), 0.01 mm (1.00 mm ... 5.00 mm) respectively, 0.01 mils (0.00 mils ... 9.99 mils), 0.1 mils (10.0 mils ... 99.0 mils), 1.0 (100 mils ... 200 mils)
- Accuracy of repeat measurements: ±(1 µm / 0.04 mils +2 %) of 0 µm ... 999 µm / 40 mils, ±3.5 % of 1001 µm ... 5000 µm / 40 mils ... 200 mils
- Minimum area of measurement: 10 mm x 10 mm / 0.4 in x 0.4 in
- Minimal radial curvature: Convex: 5 mm / 0.2 in, concave: 30 mm / 1.2 in
- Minimum base material thickness: Type F: 0.2 mm / 0.008 in, type N: 0.05 mm / 0.002 in
+
+
Overview
Specs
Reviews
PCE-CT 50 is a Thickness Gauge that takes non-destructive measurements of nonmagnetic coating, insulating layer and dry film thickness (DFT) on only non-ferrous metal substrates such as aluminum. Ideal for surface testing, automotive paint inspection, material testing and manufacturing quality control applications, this Thickness Gauge is designed to measure layers of paint, ink, plastic, enamel, paper, glass, rubber and similar materials.
