PM60A Color TFT Display Portable Handheld Pulse Rate SPO2 Oximeter Monitor + Software
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
PM60A Color TFT Display Portable Handheld Pulse Rate SPO2 Oximeter Monitor + Software
Major Features
¦Small in volume, light in weight and convenient in carrying
¦Operation of the product is simple, low power consumption
¦SpO2 value display
¦Pulse rate value display, bar graph display
¦Pulse waveform display
¦The display mode can be changed
¦Changeable light-time
¦A pulse rate sound indication
¦With measured data overruns limits and low-voltage alarm function, the upper/down alarm range is adjustable
¦With clock function
¦Battery capacity indication
¦Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage, and with alarm function
¦Connected with an external oximeter probe.
¦Trend Graph/Table: Resolution from 1s, 5s, 10s,30s,1min, and so on. Storage of latest 96 hours trend data.
¦Alarm: Adjustable High and Low limits. Three level audible and visual alarm, latest 50 alarm information and waveform displays 8 seconds which 4 seconds are before a certain time when the alarm is turned on and 4 seconds are after appointed time when the alarm is turned on.
¦Upload data: Data stored in SD card can be uploaded to computer and analyzed by SpO2 software.
Main performance
¦Display Mode: 3.5" Color TFT display
¦Screen Resolution: 320*240
¦Spo2 Measuring Range: 0%~100%, (the resolution is 1%).
¦Accuracy: 70%~100%: ±2% ,Below 70% unspecified.
¦PR Measuring Range: 30bpm~250bpm, (the resolution is 1bpm)
¦Accuracy: ±2bpm or ±2% (select larger)
¦Measurement Performance in Weak Filling Condition:
Spo2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
¦Resistance to Surrounding Light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
¦Power Consumption: less than 300mA
¦Voltage: DC 5.0V
¦Power Supply: Built-in recharge Li-Polymer
¦Battery Working Hour: 7 hours
¦Safety Type: Interior Battery, BF Type
Accessories
¦A User Manual
¦A Power Adapter (GTM41076-0605; CMS0105)
¦A Data Line
¦A Bracket
¦A Disk (PC Software)
¦An Oximeter Probe For Adult
Major Features
¦Small in volume, light in weight and convenient in carrying
¦Operation of the product is simple, low power consumption
¦SpO2 value display
¦Pulse rate value display, bar graph display
¦Pulse waveform display
¦The display mode can be changed
¦Changeable light-time
¦A pulse rate sound indication
¦With measured data overruns limits and low-voltage alarm function, the upper/down alarm range is adjustable
¦With clock function
¦Battery capacity indication
¦Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage, and with alarm function
¦Connected with an external oximeter probe.
¦Trend Graph/Table: Resolution from 1s, 5s, 10s,30s,1min, and so on. Storage of latest 96 hours trend data.
¦Alarm: Adjustable High and Low limits. Three level audible and visual alarm, latest 50 alarm information and waveform displays 8 seconds which 4 seconds are before a certain time when the alarm is turned on and 4 seconds are after appointed time when the alarm is turned on.
¦Upload data: Data stored in SD card can be uploaded to computer and analyzed by SpO2 software.
Main performance
¦Display Mode: 3.5" Color TFT display
¦Screen Resolution: 320*240
¦Spo2 Measuring Range: 0%~100%, (the resolution is 1%).
¦Accuracy: 70%~100%: ±2% ,Below 70% unspecified.
¦PR Measuring Range: 30bpm~250bpm, (the resolution is 1bpm)
¦Accuracy: ±2bpm or ±2% (select larger)
¦Measurement Performance in Weak Filling Condition:
Spo2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
¦Resistance to Surrounding Light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
¦Power Consumption: less than 300mA
¦Voltage: DC 5.0V
¦Power Supply: Built-in recharge Li-Polymer
¦Battery Working Hour: 7 hours
¦Safety Type: Interior Battery, BF Type
Accessories
¦A User Manual
¦A Power Adapter (GTM41076-0605; CMS0105)
¦A Data Line
¦A Bracket
¦A Disk (PC Software)
¦An Oximeter Probe For Adult
