What frequency bands does the Aruba AP-763 support?

The Aruba AP-763 supports 2.40 GHz, 5 GHz, and 6 GHz frequency bands.

What is the maximum wireless data rate of the Aruba AP-763 access point?

The maximum wireless data rate of the Aruba AP-763 access point is 5.80 Gbit/s.

Questions & Answers: Aruba AP-763 Tri Band Wi-Fi 7 5.80 Gbit/s Wireless Access Point - 2.40 GHz, 5 GHz, 6 GHz - MIMO Technology - Single User/Multi User MIMO - Network (RJ-45) - 5 Gigabit - Bluetooth 5.4 S4K09A

double click image to zoom in

Shop All HP Products

Aruba AP-763 Tri Band Wi-Fi 7 5.80 Gbit/s Wireless Access Point - 2.40 GHz, 5 GHz, 6 GHz - MIMO Technology - Single User/Multi User MIMO - Network (RJ-45) - 5 Gigabit - Bluetooth 5.4 S4K09A

Wi-Fi 7 (802.11be) brings multilink operation (MLO) for channel aggregation, 4K QAM for higher throughput and lower latency, and the 6 GHz band for more than double the available capacity.
Dual radio, tri-band coverage across 2.4 GHz, 5 GHz, and 6 GHz for 5.8 Gbps (6 GHz 4x4 160 MHz) Gbps peak aggregate data rate
Flexible radio delivers up to 4.3 Gbps maximum 5 GHz + 6 GHz aggregate data rate, using dual 2x2 MIMO radios (5 GHz and 6 GHz) or up to 5.8 Gbps using 6 GHz (4x4) with 160 MHz
Flexible deployment with dynamic antennas (integrated omni and directional, software provisioned)
Industrial IoT-ready platform with integrated Bluetooth and 802.15.4/Zigbee radios Fast wired connectivity with 5GbE port
Low Power Indoor (LPI) power and Standard Power (SP) device operation, where available Embedded GPS receiver for location and standard power support
Class 1 Division 2 and ATEX Zone 2 certified (AP-765EX only)2
Connectorized model supports external antennas
AI-powered dynamic power save mode helps reduce energy use

$1,899^.99 –
