HUBBELL WIRING DEVICE-KELLEMS HBL415I Straight Blade Receptacle, 5-15R, 15 A,

The HUBBELL Receptacle is a 15A, 125V AC quad outlet designed for surface mounting in commercial and industrial settings. This receptacle features four NEMA 5-15R outlets within a single device, allowing multiple connections from one location. It is constructed with a polycarbonate housing and brass contacts suitable for indoor use.

Key Features of the HUBBELL Quad Outlet Receptacle:

• Outlet Configuration: Four NEMA 5-15R straight blade outlets in a quad arrangement


• Mounting Type: Surface mount design suitable for indoor installation


• Electrical Rating: Rated for 15 amps at 125 volts AC; supports up to 1/2 horsepower loads


• Wiring Method: Back-wired screw terminals accommodate #1412 AWG copper conductors (stranded or solid)


• Material Construction: Polycarbonate base and housing with .032" brass power contacts


• Grounding: Grounded, two-pole three-wire configuration with green #8-32 brass ground screw


• Circuit Features: Anchor hole and loop feature secures solid wire; triple wipe contacts; break-off tabs allow split wiring of outlets


• Certifications & Standards: Listed to UL Standard 498, CSA Certified C22.2 No.42, meets NEMA WD-6 requirements
