CP2102 USB to DB9 Male RS232 UART Interface Adapter Converter Null Modem Communication Cable(Standard Pinout)

CP2102 USB to DB9 Male RS232 UART Interface Adapter Converter Null Modem Communication Cable
Null modem pinout( pc with usb communicate with destop pc(with DB9 com port)):
2-TXD(yellow), 3-RXD(orange),5-GND(GND),7-CTS(green),8-RTS(brown), 1/4/6/9-NC
USB to Null Modem serial adapter corrects DTE/DCE conflicts without requiring additional adapters or cables
The CP2102 chipset is highly customizable and broadly compatible, making it the ideal solution for any setup
Portable USB-Powered design requires no bulky power adapter or outlet
USB to Null Modem (Cross-Wired) RS232 Serial Adapter
Integrated CP2102 USB UART Chip
Baud Rate up to 921.6Kbps
COM Port assignments maintained across reboot
USB-powered - no external power adapter required
F1T-D2I USB to Null Modem Serial Adapter Cable (1-Port) converts an available USB 1.1 or 2.0 port into an RS232 Null Modem serial DB9 port, solving DCE/DTE conflicts directly, without requiring additional cross-wired serial cables or adapters.
USB to Null Modem (Cross-Wired) RS232 Serial Adapte
USB2.0 RS232 to DB9 female cable
CP2102+ZT213 chip
USB2.0 standard, full speed
Baud Rate up to 921.6Kb
Null modem pinout( pc with usb communicate with destop pc(with DB9 com port)):
2-TXD(yellow), 3-RXD(orange),5-GND(GND), 7-CTS(green),8-RTS(brown), 1/4/6/9-NC
Driverdownload :www.silab.com
Standard DB9 COM port pinout:pc(host) with usb to RS232 terminal device(slave)
2-RXD(yellow), 3-TXD(orange),5-GND(GND),7-RTS(green),8-CTS(brown), 1/4/6/9-NC
USB to female serial port cable allows you to connects a PC without serial port to a serial device because it adds a 9 pin DB9 port or desktop via USB port
Portable USB-Powered design requires no bulky power adapter with superior performance, offering an easy connectivity for serial pl-ug devices
Built as cp2102 serial cable for 10, 8, 7, OS8 or higher, Linux 2.4.0 and later
USB male to serial female cable is
