CAT5E-BLACK Bulk Ethernet Cable, U/UTP, Solid Bare Copper, 1000ft Pull Box, HDPE Insulation, PVC Jacket, Black, 24AWG, CMR Rated, ANSI/TIA-568-C.2
- Type: Category 5E U/UTP Cable, engineered for high-speed data, VoIP, and video applications in structured cabling systems.
- Conductor Material: Solid Bare Copper (BC), 24AWG, 0.49 mm ±0.01 for maximum conductivity and performance.
- Insulation: HDPE insulation with 0.89 mm ±0.05 diameter, 0.20 mm average thickness, ensuring electrical stability and reduced attenuation.
- Color-Coded Pairs: Blue/White-Blue, Orange/White-Orange, Green/White-Green, Brown/White-Brown for easy identification and termination.
- Jacket Material: Durable black PVC jacket with 5.0 mm ±0.3 diameter and 0.50 mm average thickness, providing protection and flexibility.
- Rip-Cord: Integrated rip-cord for clean and efficient jacket removal during installation.
- Electrical Performance: Conductor DC Resistance 93.8/km @ 20°C for low resistance and consistent signal transmission.
- Impedance: 100±15 Ohm characteristic impedance optimized for Ethernet applications.
- Temperature Rating: Operational from -20°C to +75°C for
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Type: Category 5E U/UTP Cable, engineered for high-speed data, VoIP, and video applications in structured cabling systems.
Conductor Material: Solid Bare Copper (BC), 24AWG, 0.49 mm ±0.01 for maximum conductivity and performance.
Insulation: HDPE insulation with 0.89 mm ±0.05 diameter, 0.20 mm average thickness, ensuring electrical stability and reduced attenuation.
Color-Coded Pairs: Blue/White-Blue, Orange/White-Orange, Green/White-Green, Brown/White-Brown for easy identification and termination.
Jacket Material: Durable black PVC jacket with 5.0 mm ±0.3 diameter and 0.50 mm average thickness, providing protection and flexibility.
Rip-Cord: Integrated rip-cord for clean and efficient jacket removal during installation.
Electrical Performance: Conductor DC Resistance 93.8/km @ 20°C for low resistance and consistent signal transmission.
Impedance: 100±15 Ohm characteristic impedance optimized for Ethernet applications.
Temperature Rating: Operational from -20°C to +75°C for reliability in various indoor environments.
Fire Safety: CMR-rated for use in vertical riser spaces; meets fire test standards.
Conductor Material: Solid Bare Copper (BC), 24AWG, 0.49 mm ±0.01 for maximum conductivity and performance.
Insulation: HDPE insulation with 0.89 mm ±0.05 diameter, 0.20 mm average thickness, ensuring electrical stability and reduced attenuation.
Color-Coded Pairs: Blue/White-Blue, Orange/White-Orange, Green/White-Green, Brown/White-Brown for easy identification and termination.
Jacket Material: Durable black PVC jacket with 5.0 mm ±0.3 diameter and 0.50 mm average thickness, providing protection and flexibility.
Rip-Cord: Integrated rip-cord for clean and efficient jacket removal during installation.
Electrical Performance: Conductor DC Resistance 93.8/km @ 20°C for low resistance and consistent signal transmission.
Impedance: 100±15 Ohm characteristic impedance optimized for Ethernet applications.
Temperature Rating: Operational from -20°C to +75°C for reliability in various indoor environments.
Fire Safety: CMR-rated for use in vertical riser spaces; meets fire test standards.
