RS232 to RS485 RS422 Isolated Converter 2-Way Conversion RS-485 Interface Data Serial Adapter Cable 7-36VDC
- power supply
- RS232 to RS485 RS422 Isolated Converter 2-Way Conversion RS-485 Interface Data Serial Adapter Cable 7-36VDC
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
power supply
Description:
Serial Adapter RS232 to RS422 and RS485 Data Converter
Features
Compatibility: EIA/TIA RS232C standard and RS485 standard
Interface RS232 side: DB9 female connector.
Interface RS485 side: terminal blocks
Surge protection
3-ends isolated.
15kv ESD protection
Signal Enhancement
Automatic send data control auto distinguish and sense direction adout data transfer
600W TVS protection
Transmission rate: 300 - 256kbps
Transmission distance: RS485 max.
1200m@9600bps RS232 side max. 5m
Max 256 nods
Isolation voltage : 3000Vrms
7-36VDC/500mA power supply
Working environment: -20 ~ 75 oC relative humidity 5% - 95%
Supports DOS/WIN95/WIN98/WIN2000/NT/XP Linux
Package Content:
1X RS232 to RS-485/RS-422 Adapter
==========
Model Number : DCM2610C2
DIY Supplies : ELECTRICAL
Description:
Serial Adapter RS232 to RS422 and RS485 Data Converter
Features
Compatibility: EIA/TIA RS232C standard and RS485 standard
Interface RS232 side: DB9 female connector.
Interface RS485 side: terminal blocks
Surge protection
3-ends isolated.
15kv ESD protection
Signal Enhancement
Automatic send data control auto distinguish and sense direction adout data transfer
600W TVS protection
Transmission rate: 300 - 256kbps
Transmission distance: RS485 max.
1200m@9600bps RS232 side max. 5m
Max 256 nods
Isolation voltage : 3000Vrms
7-36VDC/500mA power supply
Working environment: -20 ~ 75 oC relative humidity 5% - 95%
Supports DOS/WIN95/WIN98/WIN2000/NT/XP Linux
Package Content:
1X RS232 to RS-485/RS-422 Adapter
==========
Model Number : DCM2610C2
DIY Supplies : ELECTRICAL
