Factory Supply USB to Optical Near Infrared Irda IR Adapter Serial Interface ma~netic Adapter Cable Fit for Slimme Meter Reading

Factory Supply USB to Optical Near Infrared Irda IR Adapter Serial Interface ma~netic Adapter Cable Fit For Slimme Meter Reading
Specifications and parameters of the entire cable:

Hardware parameters: Build American CP2102 chip, powered by USB interface, without the need Fit For external power supply,

standard: transparent transmission, supporting multiple communication protocols such as IEC62056-21, IEC1107, DLMS, MODBUS, etc

USB&Driver Supports multiple versions of Windows operating systems, MacOS, Linux, and other systems;

Baud rate: Communication baud rate supports 300-19200bps

Overall dimensions: diameter: 32mm, transmitting and receiving spacing: 6.5mm

Installation: 25mm * 15mm * 5mm galvanized ma~net with strong ma~netic adsorption (as specified in IEC62056)

Environment: specified working range -25 -70

length: 2.0M

CP2102 Driver, please click here Fit For CP2102 Driver

About CP2102
Single-Chip USB to UART Data Transfer
-Integrated USB transceiver; no external resistors required
-Integrated clock; no external crystal required
-Internal 1024-byte programmable ROM Fit For vendor ID, product ID, serial number, power descriptor, release number, and product description strings
- EEPROM (CP2102)
- EPROM (One-time programmable) (CP2109)
-On-chip power-on reset circuit
-On-chip voltage regulator
- 3.3 V output (CP2102)
- 3.45 V output (CP2109)
-100% pin and software compatible with CP2101
USB Function Controller
-USB Specification 2.0 compliant; full-speed (12 Mbps)
-USB suspend states supported via SUSPEND pins
Asynchronous Serial Data BUS (UART)
-All handshaking and modem interface signals
-Data formats supported:
- Data bits: 5, 6, 7, and 8
- Stop bits: 1, 1.5, and 2
- Parity: odd, even, mark, space, no parity
-Baud rates: 300 bps to 1 Mbps
-576 Byte receive buffer; 640 byte trans
