DS18 - DDX6.9 - 6.9" Touchscreen Double-Din Headunit with DVD, Bluetooth, USB

Brand New

DS18 - DDX6.9

6.9" Touchscreen Double-Din Headunit with DVD, Bluetooth, USB

Key Features:

Rated power source:KEY_TAB 14.4V DC (10.8V to 15V operation)

Maximum Current Consumption: 10 Amp

Dimensions (W x H x D): Chassis: 178mm x 100mm x 165mm

Bezel frame: 170mm x 96mm x 5mm

Weight: 1.52 Kg

Display:

Screen Size / Aspect Ratio: 9 inch / Wide 16:9

Pixels: 1024 x 600

Display Type: IPS / WSVGA / Capacitive Touch Screen

Temperature Operation: -20o C to +60o C (14o F to 140o F

Audio:

Maximum Power Output: 40W x 4 Ch / 4 ohm

Continuous Power Output: 15W x 4 Ch / 4 ohm

Pre-output Level: 4.5 Volts (Front, Rear) 7 Volts (Subwoofer)

Equalizer: 10 bands (35Hz, 60Hz, 80Hz, 120Hz, 160Hz,

16 bands (35Hz, 60Hz, 80Hz, 120Hz, 160Hz,

250Hz, 320Hz, 400Hz, 600Hz, 800Hz, 1KHz, 3KHz,

5KHz, 8KHz, 12.5Khz, 16Khz)

Gain: +/- 12dB

Audio Control: Volume / Balance / Fader / Subwoofer Level

Tuner:

Frequency Range: FM: 87.5 ~ 107.9 KHz AM: 530 ~ 1710 KHz

Presets Memory: 30 Stations (18 FM/12 AM)

Region: Selectable (USA, Latin, Japan, Asia, Europe, OIRT, Australia, Mid-East)

Sensitivity Adjustment: LOC (On/Off) / ST (On/Off)

DVD Player:

Format Files Supported: DVD-V, VCD, SVCD, MP3, WMA, DivX, MPG4

Region Number: 1 / Multi Region Selectable

Usable Discs: CD, CD-R, CD-RW, DVD-R, DVD-RW, DVD-RDL

USB / SD Player:

Type / Class: V1.1 / V2.0 / MSC / MTP / FAT16 / FAT32 / NTFS

Format Files Supported: RMVB, MPG4, AVI, MP3, WMA, JPEG, DivX

Resolution Supported: 1080P Video

Memory Size Reader: up to 64 Gb

Max Current Supply: 1.5 Amp (USB)

Number of USB Ports: 2 (1 x Front, 1 x Rear)

Connectivity:

Bluetooth Version / Services: V4.1 / Audio Streaming / Hands Free calls

Wi-Fi:KEY_TAB KEY_TAB Built-in

Camera Input: RCA Analog Video up to HD 720p (Front/Rear)

Video Output: Dual RCA (1 Volt/75 ohm)

A/V Aux Input: Rear RCA Audio and Video / Front 3.5mm Jack Stereo Audio

Microphone: 3.5mm Jack external MIC Input

Remote Control: Frontal IR Receptor / Wired Input / CAN-Bus Protocol

Other Info:

Product Dimensions: 8 x 6 x 3 inches

Item Weight: 5.98 pounds / 95.68 Ounces
