Specifications
How to Install The solenoid Relay




Specifications
| Voltage | 36VDC |
| Resistance | 14O |
| Capacity | 10.2W |
| Max Transient Flash Current | 300Amp |
| Continuous Working Current | Under 150Amp |
| Replaces | 70-111224 3635820 1114208 1114218 1114223 1114534 1114547 |
| Contact Studs | 5/16 -24 Studs Standard & Long |
| Bracket mounting | Holes 5/16 x 19/32 2-13/64 on Center |
How to Install The solenoid Relay
