DS18 Single Din Headunit Digital Media Receiver Mechless Bluetooth USB SDX1M

DS18 Single Din Bluetooth Receiver With Mechless USB SDX1M

This SDX1M mechless single din, perfect fit unit pushes out 50 watts max for all 4 channels while the pre-amp output is adjustable up to 7v, which is very important for maximizing the most out of your amplifiers and getting the cleanest sound while maintaining high volume levels. Mechless means this unit has no CD/DVD player. However, there is a USB, SD, and BT reader that are used for the main file sources that stream and read up to 64GB drives. Radio stations will come in strong and clear and can be set on any of the 18 memory locations.

You can also set the colors of the unit because of the backlit RGB keys to match your mood or existing color schemes, while the easy to read 3 inch VA white display remains bright and clear.

Features

Mechless Single Din USB/BT Receiver
Single Din Perfect Fit Mounting
FM Radio: 18 Memory Locations
Source: USB, SD, BT Reader / Streamer
Supported Media Files: MP3, WMA, FLAC, MAV
Remote control: Infared
RGB: 7 Selectable Colors
Display: 3" VA White Backlit
Power: 50 x 4 Watts Max
Equalizer: 2 Bands with Adjustable Bass, Treble, and Subwoofer
Pre-amp output: 7v
Inputs: USB, SD, BT, Front AUX
Rated power source 14.4V DC (11V to 16V operation)
Maximum Current Consumption 10 Amp
Dimensions (W x H x DI: Chassis 178mm x 50mm x 150mm
Bezel frame 188mm x 58mm x 30mm
Weight 15.9 Oz / 452 grams
Screen Size 3 / 75 x 25mm
Display Type VA LCD
Temperature Operation -20°C to +60°C (14°F to 140°F)
Maximum Power Output 50W X 4 Ch @ 4 ohm ( 14.4 v)
Continuos Power Output 17W x 4 Ch @ 4 ohm ( 14.4 v)
Pre-output Level 7 Volts ( 14.4V )
Equalizer 2 bands (Bass: 60Hz, Treble: 10KHz)
Gain +/- 7dB
Preset EQ Jazz / Rock / Pop / Classic
Audio Control Volume / Balance / Fader / Loudness / Bass / Treble
Subwoofer Control Vol (0-20) / Cut (80/120/160 Hz)
Signal to Noise Ratio >60dB
THD <0.3%
Frequency Response 20Hz 20Khz
Frequency Range FM: 87.5 ~ 107.9 KHz
Presets Memory 18 Stations
Region North America USA
Sensitivity Adjustment LOC / DX & ST / Mono
Sensitivity <20dB
Stereo Separation >25dB
Type/Class V 1.1 / V 2.0 / MSC / MTP / FAT16 / FAT32 / NTFS
Format Files Supported MP3, WMA, FLAC, MAV
Info Display Format ID3 Tag
Memory Size Reader up to 64 Gb
Max Current Supply 1.5 Amp (Charging USB port)
Number of USB Ports 2 x Front (1 for Audio / 1 for Charging)
SD Slot 1 x Front Micro SD
Bluetooth Version / Services V 4.1 / Audio Streaming / Hands Free calls
Audio Protoco A2DP v 1.2 Sink (SNK)
Aux input Front 3.5 mm Jack Stereo Audio
Microphone Built-In Microphone on faceplate
Remote Control Frontal IR Receptor
