Function introduction
DVR with video/photo/playback function. You can automatically adjust the mode you want:
A) Recording mode
- After pressing the power on/off button or connecting the car charger, the DVR will automatically enter the recording mode and start recording. (Note: Please insert the T? card before use.) The blue indicator light will flash at this time.
- The video file is stored in the T? card, press the OK confirmation button to stop recording, at this time the blue indicator light will stop flashing.
B) Photo mode
- Power on and press the mode key to enter the photo mode. Press the photo button 6 to take pictures.
C) Playback mode
- Power on and press the mode key twice to enter the playback mode, press the up and down keys to select the file to browse, press the video key to enter the directory, and then press the video key "play/pause.
D) Delete function
- In playback mode, press menu key to enter delete interface, then press OK key to enter select delete interface, use up/down key to select the listed settings, press OK key to delete, you can also select "thumbnail display" and "preview playback volume level" function finally press OK key to confirm. key to confirm.
Car recording instrument instructions for use:
Power supply (two ways):
- A) using built-in rechargeable lithium battery
Charging method:
1) Connect the car charger.
2) Connect the computer with USB
During charging, the red indicator light is on. When the DR is full, the red indicator light goes off.
Note: When using lithium battery power, you need to press the switch button to start or shut down the DVR recording.
- B) Connect 12V/24W car charger
After the car starts, the DR will start recording automatically. Stop working after power failure, and automatically save its front file. Note: Only use the car charger with 5V output.
HD Lens
1.6-inch color display, easy to adjust the shooting screen and display the current shooting status, 1080P HD screen recording, providing excellent image quality
Parking monitoring
Self-contained collision wake-up parking monitoring, when a collision vibration emergency start recorder recording
Loop recording, automatic deletion
Fully automatic loop overlay technology automatically produces coherent video clips, automatically clears previous useless videos when memory is full, while not accidentally deleting useful locked videos
How to Use
1. Insert the memory card into the driving recorder card slot
2. Please use a high speed memory card (Class10 or above) with a capacity of no less than 512MB
3. Fix the driving recorder on the vehicle
4. Insert the car charger into the cigarette lighter
5. Connect the USB interface of the driving recorder to the vehicle charger with the charging extension cable
6. During wiring, the charging extension line can be laid along the windshield edge.
7. Adjust the lens position to ensure that the lens is level with the ground
Specification
Item Type: Driving recorder
Material: Plastic, metal
Weight: Approx. 166g/5.9oz
Video Resolution: 1080P 720P VGA interpolation
Save Format: AVI
Battery Information: Lithium ion battery 100mAh(Shipped with built in battery)
Other Function: With voice recording function
Display Screen: 1.6in color display screen
Support Small Memory Card: Support up to 32GB(Excluded)
Adapter Input: DC 12-24V
Adapter Output: DC 5V±5% 1A
Package List
- 1 x Host
- 1 x Bracket
- 1 x Power Cord
Note:
1) Please insert TF memory card before recording.
2) This DVR recording mode can be selected to loop recording, when the memory card is full the DVR will automatically start recording again from the original memory card and overwrite the old file. (Note: In order to avoid deleting all the old files, when recording, the saved files are about 2 minutes / 5 minutes / 15 minutes as a subsection, when the SD/MMC memory card is full and re-recording, the old files will be overwritten one by one)
3) When the lithium battery power is low, the DVR screen will display "insufficient power" and automatically shut down after 20 seconds
